Long Range FC-302 450~490MHz 1~5 W Data Radio

Product description

FC-302 is a synthesized 5-watt FM transceiver module, which is designed for data transportation and voice communication. For the voice communication, it can support selected pre-emphasis, squelch and audio amplifier. Two-point modulation with good low-frequency response is applied in the radio that makes it a competitive choice for 1200-19200bps data rate application. Compact dimension and wide range DC support make it flexible to use.

Key Features

• CE, FCC& AS/NZS 4295: 2004 certified
•  Programmable 16 channels with Dip-Switch
• Configurable power saving feature
•  Optional external channel change
• FSK, FFSK& GMSK modem option
•  Frequency step 5 KHz/6.25KHz
• CTCSS/DCS
• Support maximum RF data rate: 19200bps
• Fast start-up time: 5ms
•  SQ programmable via PC
•  Pocsag Modulation support
•  PC programmable & Software tune & Calibration

Technical Specifications
GENERAL

• Working Frequency 450MHz~490MHz
• Channel Spacing 12.5KHz/25KHz(Programmable)
• Number of Channels 16
• Working Voltage 9V-18V DC(Extreme)
• Operating Temperature -30℃~+65℃
• Storage Temperature -40℃~+80℃
• Lock Time <5ms
• Frequency Error <2.5ppm

TRANSMITTER

• RF Power 1~5W(Programmable)
• Frequency Deviation <5KHz(25KHz)
• <2.5KHz(12.5KHz)

Subsonic 0.5KHz

• Audio Response 300Hz~3KHz +1/-3dB (25KHz)
• 300Hz~2.55KHz +1/-3dB(12.5KHz)
• Adj. Channel Power <-70dBc(25KHz)
• <-65dBc(12.5KHz)
• TX SNR >45dB(25KHz) >40dB(12.5KHz)

ACCESSORIES

• BNC Antenna
• PC Programming Software
• Cable(Serial)
• Extender for Service and Alignment
