Best Price Soda Water Filling Equipment

Best Price Soda Water Filling Equipment thumbnail-1
Best Price Soda Water Filling Equipment thumbnail-2
Best Price Soda Water Filling Equipment thumbnail-3
Best Price Soda Water Filling Equipment thumbnail-4
Best Price Soda Water Filling Equipment photo-1
Best Price Soda Water Filling Equipment photo-2
Best Price Soda Water Filling Equipment photo-3
Best Price Soda Water Filling Equipment photo-4
US$ 9,000 - 22,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, water, Carbonated Drink
Packaging Type:
Bottles
Contact Supplier Request Quote Chat Now
Zhangjiagang Jiazhou Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai for soda water filling equipment
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Other, water, Carbonated Drink
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 220V
Power 2.2KW
Place of Origin Jiangsu, China
Brand Name JIAZHOU
Model Number DCGF
Dimension(L*W*H) 2500*2900*2550mm
Weight 2T
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

P/roduct information Zhangjiagang Jiazhou Machinery Co., Ltd.

Product description Best price soda water filling equipment

1.Rinsing machine

-Rotative rinsing turret one treatment, fixed nozzles, with grippers.

-The grippers take the bottles from the inlet starwheel while they are still driven by the starwheel, thus guaranteeing a safe grip.

-After the gripping, the bottle is turned upside down and centred above a spraying nozzle which directs a stream of rinse water into the bottle. After the draining period the bottle is turned over to an upright position again.

2. Filling machine

-The starwheels drive the bottles always by the neck through the rinsing, filling and capping steps. For the various types of bottle, it is easy to adjust the structure for the operator by our specialized design.

- The filling valves are fully made of stainless steel with food grade, sterilization-resisting plastic gaskets. The valves are secured to the bowl and allow easy assembly and disassembly.

3. Capping machine

-Rotative capping turrent, suitable to the application of aluminum screw cap or metal crown caps on glass bottles

-The fixed part consists of the cap hopper, the cap feeder with relevant motor and the cam actuating the capping heads.

-The heads are raised and lowered by the action of a follower that is riding on a shaped cam.

Product display Best price soda water filling equipment

Best price soda water filling equipment



 Best price soda water filling equipment

Best price soda water filling equipment

Product Parameters Best price soda water filling equipment
Model DCGF
18186		 DCGF
24248		 DCGF
323212		 DCGF
404015		 DCGF
505018		 DCGF
606020
Head of washing, filling, sealing 18-18-6 24-24-8 32-32-8 40-40-10 50-50-18 60-60-20
Production capacity (bottle/hour)   3000-4000 5000-6000 7000-8000 9000-10000 11000-12000 15000
Suitable bottle diameter(mm) φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310 330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100 H=150-310  330-1500ml φ=50-100  H=150-310  330-1500ml
Filling precision ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm ≤±5mm
Motor power 3.84kw 4.1kw 5.6kw 7.5kw 9kw 11kw
Filling pressure ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4
Overall dimension     (mm) 2400×1900
×2300		 2800×2100
×2300		 4200×2300
×2300		 5000×2800
×2400		 5900×3100
×2400		 6500×3500
×2400
Weight(Kg) 3000 4000 5000 7500 9000 11000
Best price soda water filling equipment
C/ompany information Zhangjiagang Jiazhou Machinery Co., Ltd.
Best price soda water filling equipment
O/ur advantage Zhangjiagang Jiazhou Machinery Co., Ltd.
Best price soda water filling equipment
O/ur certificate Zhangjiagang Jiazhou Machinery Co., Ltd.
Best price soda water filling equipment
N/etwork Marketing Zhangjiagang Jiazhou Machinery Co., Ltd.
Best price soda water filling equipment
P/ackaging & shipping Zhangjiagang Jiazhou Machinery Co., Ltd.
Best price soda water filling equipment
C/ontact us Zhangjiagang Jiazhou Machinery Co., Ltd.
Best price soda water filling equipment
