Zhangjiagang small bottle capacity beer bottling machine/beer filling machine / automatic beer machine

         small bottle capacity beer bottling filling machine / automatic beer machine

Introduction

we have developed the latest beer filling machine in accordance with the technological requirements for packing beer in glass bottles by adopting advanced technologies both at home and abroad. Meanwhile, we are able to provide complete high-efficiency beer filling production line for the beer breweries.

Description

This machine design on the basis  of absorbing domestic and foreign advanced technology,and integrates washing,filling and capping function in one unit,and mainly for filling glass bottle carbonated drink,such as spirit,cola,cocktail,etc,adopts high precision machanical filling valves,has features of no bottle,no vacuuming.

Opening gear combined gear box transmission,with engaging and disengaging gear device,frequency conversion extends the speed modulation range.This machine has self oil lubrication device so than the lubrication points could be lubricated regularly in time.The machine is high efficiency,low noise and long life.The some parts of machine can be adjusted by different sizes bottle.the level is controlled by the electric probe to assure the precise the liquid level.

Features

1.With high precision me chanical filling valves,our beer filling machine stops vacuumizing when there are no  bottles.

2.The beer filling machine is equipped with external mechanical valve,inside which there is no spring or sealing element.

3.With high pressure frothing device,it is capable of double vacuum-pumping.

4.The beer filling machine makes use of combined transmission by open gear and gearbox,and adopts   frequency conversion stepless speed control,extending the speed modulating scope.

5.The machine has an antomatic lubricating device so that the lubrication points can be automatically lubricated regularly in time.Also,our beer filling machine has high transmission efficiency,low noise and long life.

6.In case of the blowout due to poor quality of the bottles during gas or beer filling,the filling valve will automatically close and the auto-cleaning device will work to treat the broken bottles.

7.With a full stainless steel magnetic hopper,the unscrambling, feeding and discharging of crown caps are all performed by magnetic force.The caps are free from deforming,and can flow smoothly in large quantities during transmission.

8.The capper has the function of automatic deloading,which helps lower the bottle breakage.

9.For the centering guide of our beer filling machine,we adopt double guide-bar mechanism,with the function of pre-covering which allows stable and reliable bottle transferring.

10.The movement of the wine jars and capping heads is driven by electricity in order to fit bottles of different sizes.

11.The material height in the tank is controlled by electric probe so as to ensure precise liquid level and reliable filling.

Characteristics

(1) The whole machine adopts card bottle hanging running state design, so that the bottle under high-speed operation stable and reliable. Change a few fittings, Can be quickly and easily implement different bottle production need.

(2) Using a new generation of tilting bottles clamp, stainless steel clamps and the bottle thread above part does not contact, bottle clamp with shower, to wash the bottle of any part of the wall.

(3) Using advanced micro gravity type negative pressure filling principle, filling fast, stable and accurate. Silos is fully enclosed structure, there is the function of temperature control and automatic reflow, and provide the CIP cleaning interface.

(4) This machine  satisfies the requirement :of below 95 degrees Celsius hot filling technology, before-capping,  equipped with bottle  R.O. water flushing device, To ensure that the bottle no moldy phenomenon.

(5) Using magnetic torque type screw cap, Pincer-like device tight and reliable and  does not hurt cover.

(6) The machine adopts the man machine interface, PLC computer control, touch screen button. there is lack of cover, overload protection and alarm device, can timely detection and troubleshooting, high degree of automation of production

(7) And material contact parts adopt high quality stainless steel manufacturing, the main electric components and pneumatic components adopt international famous manufacturers.

Image of automatic beer machine

1.The washing part:

2.The filling part:

3.The capping part:

Main Technical Parameter

Our service:
1.Jiazhou company can provide turn-key project for you, only you have any idea to start beverage factory plant.
2.Jiazhou company have professional design team, our engineer can draw bottle samples and flow chart of
workshop for you .
3.Jiazhou company give you the best quotation for all kinds of beverage production, only you can tell me which kind of drink you want to product, what is your capacity(how many bottles one hour) what is you bottle material, pet or glass,etc
Aftersale service:
1. We send the engineers to help installing, commissioning and training, the engineers start from our factory area.
2. We supply below necessary documents with the machine:
a. Machine layout
b. Electricity diagram
c. Machine certificate
d. General manual book/maintenance book
3. After one year guarantee, the seller provides payable spare parts and technician’s VISITING maintenance service.
