Glass Bottle Red Wine Filling Equipment

Automatic Red Wine Filling Line / Facility / Machine

The line intergrates rinsing,filling and capping together.

Description of the Machines

1, Glass Bottle Rinsing Line (ZPC automatic type)

(1). Rinsing Capacity : 2000-3000bottles / hour

(2). Fitting Bottle Size: Height: 150-300mm

(3) Diameter: 50-90mm

(4). Running Method: Continuous Gyration Running

(5). Number of Rinsing Position: 12 Pieces

(6). Power of the Machine: 1.5 kw

(7). Overall Weight of the Machine: 700kg

(8). Overall Dimensions: 1400×1200×1800mm

2. Filling Line

This line is ideal auto-filling device.

(1). Range of bottle volume : 250-1250ml glass bottles or PET bottles

(2). Range of bottle size:

a. Diameter of bottle : 50-90mm

b. Height of bottle : 200-330mm

c. Inner-diameter of bottle: ≥17mm

Capacity: 1500-2500bottles / hour

Power of the main motor : 1.2Kw

Overall dimension : 920X800X1940mm

Total weight: 500Kg

The line is composed of water tank, float ball, shaft, filling valve, pneumatic component, electric machine.

Dimension: 1400*800*2200

Including:

Water pump: southern pump

Pneumatic component: AUTONICS BRAND

Programmed controller: SANLING BRAND

Touch machine: THINEDA BRAND

Photo electricity: Korea

Filling heads: 12heads bottle available: 250ml-1000ml diameter of bottle body no more

than 9600mm, height no more than 90mm.

3. Capping Line for ROPP Aluminum Cap

(1). Capacity : 6 heads 2000~3000botlles/hour

(2). Running method : continuous gyration

(3). Specification of bottle: height of bottle 140-300mm

(4). Specification of bottle lid : diameter of bottle lid: 20-30mm

(5). Lid-screwing position: 6 pieces

(6). Speed reducer : m=3 i=41:1

(7). Total weight of machine: 800kg

(8). Over dimension: 1110x860x2200mm

Technical Features:

1.Filling valve adopts high precision mechanical filling valve, with the character of no bottle no vacuum pumping.

2.Open gear combinated gear box transmission, with on-off device.Frequency conversion velocity modulation device extends the speed modulating scope.

3.This automatic red wine filling line / facility / machine has self oil lubrication device so that the lubrication points can be lubricated regularly in time.

4.This automatic red wine filling line / facility / machine is of high efficiency,low noise and long life.

5.Centering guide is of double guide bar type, with the function of pre-covering.

6.Wine jar and capping head are driven by manual, also can be driven by electricity to fit different sizes of bottles.

7.The material height in the tank is controlled by electric probe to assure the precise liquid level.
