(hot sale) Beer/Wine Filling Equipment
Description:
1, The beer filling equipment using high-strength stainless steel bottles of spring-loaded folders, to ensure a stable reversal of the glass bottles. The nozzle is a plum-like structure can wash every corner of the sidewall and bottom to make the bottle clean.
2, Filling equipment with spring-type mechanical lifting equipment to upgrade glass bottles, large bearing support floundering in the vat and use of guide-rod in the orientation of the structure, there are pre-cover features.
3, Using high-precision mechanical filling valve, with cylinder liquid level and the back pressure controlled by a variable signal proportional. Fast, stable, accurate, to be vacuum one at a time.
4, Stainless steel plunger and mechanical stirring gland-type magnetic reasonable cap to ensure that the gland is healthy and reliable. Hopper and the cap taking- cover, capping transmitted by magnetic. The capping is reliable and automatic unloading, reducing the rate of broken bottles.
5, Before the capping, use hot water bubble set to displace bottlenecks air, ensuring the oxygen content of less than 0.15mg / L.
6, Filling equipment includes broken bottle automatically stopping valve, broken bottle washing, and foam automatically exhausting device.
7, With perfect CIP cleaning function, and capable of rinsing filling pipes with acid, lye liquid and hot water.
8,All the materials in contact with the valves, tanks, pipes are made of stainless steel N304 materials, inside and outside the wall of mirror-polished, ensuring it is healthy.
9, Manually dry oil lubrication system to make sure equipment maintenance is more convenient.
10, The whole operation adopts advanced man-machine interface, PLC control, frequency conversion stepless speed regulation and other automatic control technology, with no bottle no open valves, no stamps; no cap no operation, and other security protection.
Technical parameters:
Model |
Washing heads |
Filling heads |
Capping heads |
Capacity(b/h) 500ml |
Motor power (KW) |
Overall dimension (mm) |
BFG14-12-5 |
14 |
12 |
5 |
1000bph |
1.5KW |
2100x1400x2500 |
CGF18-18-6 |
18 |
18 |
6 |
2000bph |
2.2KW |
2460x1720x2650 |
CGF24-24-8 |
24 |
24 |
8 |
3000bph |
3KW |
3100x2100x2650 |
CGF32-32-10 |
32 |
32 |
10 |
6000bph |
4KW |
3500x2500x2650 |
CGF40-40-10 |
40 |
40 |
10 |
8000bph |
7.5KW |
4600x1800x2650 |
CGF48-48-12 |
48 |
48 |
12 |
9000bph |
9.5KW |
5200x4500x3400 |
CGF60-60-15 |
60 |
60 |
15 |
12000bph |
12KW |
6500x4500x3400 |
related machine--------warmer machine
ink jet printer
PE film packing
WATER TREATMENT:
1. stretch film packaging to save container space
2. standard wooden case to protect machine's important part.
Our Service:
1. one year gurantee, free charge for spare parts in warranty.
2. engineer available to service overseas.
3. good quality competitive price. ISO9001:2008 and BV certificate
Company Information
Company Introduction
Zhangjiagang Jiazhou Machinery Co.,Ltd is a manufacturer in beverage machine field for about 15 years. She has her own factory which is founded in year of 1998. Her sale company Zhangjiagang Jiazhou Machinery Company Limited is set up in 2005. Jiazhou has entered into international trade in 2008, now is 7 years old on Alibaba.
Jiazhou has well cooperated with many clients in many countries and areas, such as Kenya, Nigeria, Malaysia, Vietnam, Bangladesh, Ghana, Madagascar, and Middle East Area. She also has popular market in China, received very good reputation.
Jiazhou shall make progress with clients and market. Her aim is to establish credibility and pursue specialized quality and service. Choose Jiazhou as business partner, you can get assured about the quality.
