automatic wire mesh welding machine
Function Characteristics:
This wire mesh welding machine adopts electrical synchronous control technique, both welding time and separate-control welding is composed of digital and integrated electric circuit. This operation is accurate , it has stable function , firm welded point, and without welded tracks. Not only welding speed is fast, but also it is easy to learn and operate. Fallen weft structure and drawing materials are automatic, so it is even and accurate , the edge of mesh is regular, it is unnecessary to slice the ends, drawing mesh system adopts the device with elastic tension link and fixing mesh , it is easy to regulate mesh hole, and mesh size is rather accurate, welding aperture could also adjust randomly within range.
Use of The Product:
1. welding for breed aquatic mesh (poultry mesh)
2. welding building mesh(reinforcing mesh, floor warming mesh, seed-bed mesh and room mesh).
Main parameter:
|
JK-120A-1 |
JK-120A-2 |
JK-120A-3 |
Input power |
380V 50Hz |
380V 50Hz |
380V 50Hz |
Max. width |
1200mm |
1200mm |
1000mm |
Line wire space |
50-200mm |
50-200mm |
100-200mm |
Cross wire space |
50-200mm |
50-200mm |
50-200mm |
Wire diameter |
1.4-2.5mm |
1.4-2.5mm |
1.4-2.0mm |
Rated capacity |
56kva*3 |
56kva*2 |
56kva*1 |
Welding point No. |
25 |
25 |
11 |
Motor power |
2.2KW |
2.2KW |
2.2KW |
Feed line wire |
Coil wire |
Coil wire |
Coil wire |
Feed cross wire |
Coil wire |
Coil wire |
Coil wire |
Cutting mesh |
Automatic & Manual |
Automatic & Manual |
Automatic & Manual |
Welding speed |
60 times/min |
60 times/min |
60 times/min |
Weight |
2500kg |
2000kg |
1700kg |
Dimension(L*W*H) |
2500*1800*1400mm |
2500*1800*1400mm |
2500*1800*1400mm |
