Automatic Steel Rod Straightening and Cutting machine
1.This machine mainly consists of tray bar rack,straightening rack,tractor cutting device,base support, motor rotation facility and control box of electric appliances.
2.This machine is applicable to straighten and to cut all types of metal wire.
Automatic Steel Rod Straightening and Cutting machine
Model | SC1.5-3.5 | SC2-5 | SC4-8 | GT4-12 | GT6-14 |
Dia.mm | 1.5-3.5 | 2-5 | 4-8 | 4-12 | 6-14 |
Cut Length mm | 30-2000 | 30-6000 | 200-6000 | 500-12000 | 800-12000 |
Cut Error mm | ±1 | ±1 | ±1 | ±5 | ±5 |
Speed m/min | 25 | 30 | 35 | 45 | 55 |
Straight Motor kw | 1.5 | 1.5 | 4 | 11 | 11 |
Cutting Motor kw | 0.75 | 0.75 | 3 | 4 | 4 |
Overall Size M | 1.7*0.4*0.8 | 1.2*0.4*0.9 | 7.3*0.6*1.2 | 8*0.8*1.3 | 2.7*0.8*1.2 |
Weight KG | 130 | 150 | 650 | 1000 | 1200 |
Automatic Steel Rod Straightening and Cutting machine
GT4-12
SC1.5-3.5
GT4-8
After straighteing and cutting
1. Designing and manufacturing the highest quality wire product machine for the worldwide market.
2. Carring out general engineering work of the highest standard.
3. Providing the best and most competitive quality products through innovative techniques and dedicated product support.
4. Committing to meeting set objects by continuous improvement.
5. Strive to exceed our customers' experience.
1.Guarantee time: one year since machine was at buyer's factory but within 18 months against B/L date.
2.Within guarantee time, if any components are broken under normal condition, we can change for free.
3.We can send our best technician to buyer’s factory for installation, debugging and training.
4.Complete installation instructions, circuit diagram, manual operations and machine layout.
5.24 hours technical support by e-mail.
Package:The machines are packed with plastic bags and then packed in wooden box fastened with rope.
Transportation : Shipping or train.
Payment Terms:
1, 30% by T/T as deposit , 70% by T/T after inspect the machine at seller's factory before shipping
2, Irrevocable L/C at sight.
Service:We
Inquiry now, and I will reply ASAP!!!
Welcome to our factory!!!
