5-12mm hydraulic wire straightening and cutting machine/wire straighten and cut off machine
- 20 Set / Sets per Month
- TIANJIN
- T/T
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Solar panel recycling machine with high efficiency
- Micro wire mesh weaving machine from LANYING wire mesh weaving machine
- LANYING woven wire mesh machines - stainless steel wire mesh weaving machines
- Jotun JT-SDJ Industrial Automatic Metal Sheet Surface Polishing Machine
- Large Metal Sheet Metal Workpiece Processing Deburring Chamfering Plane Belt Polishing Machine
Product Details
Place of Origin: | Hebei, China | Brand Name: | JIAKE | Model Number: | JK-SCH5-12 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
wire straightening and cutting machine/wire straighten and cut off machineautomatic
stable
easy to operate
guarantee:1year
5-12mm hydraulic wire straightening and cutting machine/wire straighten and cut off machine
5-12mm hydraulic wire straightening and cutting machine/wire straighten and cut off machine
Machine
This machine mainly consist of tray bar rack,straightening rack, cutting device,base support and control box of electric appliance,
Usage
the machine is used to straightening and cutting all types of metal wire
we have 6 model:
SC1.5-3.5MM for 1.5-3.5mm wire
SC2-5MM for 2-5mm wire
SC3-6MM for 3-6mm wire
SC4-8MM for 4-8mm wire
SC5-12MM Mechanical for 5-12mm wire
SC5-12MM Hydraulic for 5-12mm wire
5-12mm hydraulic wire straightening and cutting machine/wire straighten and cut off machine
Model | JK-SCH5-12 |
Dia.mm | 5-12 |
Cut Length mm | 700-9000 |
Cut Error mm | ±10 |
Speed m/min | 45 |
Straight Motor kw | 11 |
Cutting Motor kw | 4 |
Overall Size M | 1.9*0.6*1.4 |
Weight KG | 900 |
Other Models:
Model | JK-SC1.5-3.5 | JK-SC2-5 | JK-SC3-6 | JK-SC4-8 | JK-SC5-12 |
Dia.mm | 1.5-3.5 | 2-5 | 3-6 | 4-8 | 5-12 |
Cut Length mm | 30-2000 | 30-6000 | 30-6000 | 200-6000 | 200-6000 |
Cut Error mm | ±1 | ±1 | ±1 | ±1 | ±1 |
Speed m/min | 25 | 30 | 35 | 35 | 30 |
Straight Motor kw | 1.5 | 1.5 | 2.2 | 4 | 7.5 |
Cutting Motor kw | 0.75 | 0.75 | 0.75 | 3 | 4 |
Overall Size M | 1.7*0.4*0.8 | 1.2*0.4*0.9 | 1.3*0.55*1.1 | 7.3*0.6*1.2 | 8*0.8*1.3 |
Weight KG | 130 | 150 | 200 | 650 | 1000 |
5-12mm hydraulic wire straightening and cutting machine/wire straighten and cut off machine
Products:
5-12mm hydraulic wire straightening and cutting machine/wire straighten and cut off machine
Hebei Dapu Import & Export Trade Co.,Ltd is engaged in designing, manufacturing and exporting metal & wire mesh processing machinery, different kinds mesh weaving and wire mesh welding machine which located in Shijiazhuang Hebei China.It has own factory-Hebei Jiake Welding Equipment Co.,Ltd located in industrial zone ,Anping, Hebei ,China.It is the leading manufacturer of mesh machine in China and we always offer advanced wire mesh technology.
