Automatic straightening and cutting wire machine factory
straightening rack
Finished product
Wire straightening machine mainly consists oftray bar rack,straightening rack,tractor cutting device,base support,motor rotation facility,control box of electric appliances
parameter of the wire straightening machine
Model | SC1.5-3.5 | SC2-5 | SC4-8 | SC4-12 | GT4-12 | GT6-14 |
wire diameter mm | 1.5-3.5 | 2-5 | 4-8 | 4-12 | 4-12 | 6-14 |
Cutting length mm | 30—2000 | 30-6000 | 200-6000 | 200-6000 | 500—12000 | 800-12000 |
Cut error mm | ±1 | ±1 | ±1 | ±1 | ±5 | ±5 |
Speed m/min | 25 | 30 | 35 | 30 | 45 | 55 |
Straight motor kw | 1.5 | 1.5 | 4 | 7.5 | 11 | 11 |
Cut motor kw | 0.75 | 0.75 | 3 | 4 | 4 | 4 |
Overall size m | 1.7X0.4X0.8 | 1.2X0.4X0.9 | 7.3X0.6X1.2 | 8X0.8X1.3 | 2.1X0.7X1.3 | 1.9X0.6X1.4 |
Weight kg | 130 | 150 | 650 | 1000 | 1000 | 12000 |
Hebei Jiake Welding Equipment Co.,Ltd
Address:Wire Mesh Insdustrial Zone, Anping County, Hebei Province, China
Sales: Jenny
QQ:3050875416
Skype: dapu_machine
Whatsapp:
If you need the machine, Just contact me anytime !
