Automatic Wire Straightening and Cutting Machine

Automatic Wire Straightening and Cutting Machine photo-1
Automatic Wire Straightening and Cutting Machine photo-2
Automatic Wire Straightening and Cutting Machine photo-3
Automatic Wire Straightening and Cutting Machine photo-4
Automatic Wire Straightening and Cutting Machine photo-5
Automatic Wire Straightening and Cutting Machine photo-6
US$ 800 - 4,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
JIAKE
Model Number:
SC
Payment & Shipping
Payment Methods:
Port of Shipment:
XINGANG PORT China
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Brand Name JIAKE
Model Number SC
After-sales Service Provided Engineers available to service machinery overseas

Automatic Wire straightening and cutting machine

Director:Edson an

Mobile: 0086-15930180627 (whatsapp/viber)

Skype: dapu-machine

Wechat:edson652113

Type the below picture is the machine working Video

Automatic Wire straightening and cutting machine





Automatic Wire straightening and cutting machine

Description

This machine mainly consists of tray rack,tractor cutting device,base support,motor rotation facility and control box of electric appliances.This machine is applicable to straightening cutting of all types of metal wire.



Technical parameter

Model

SC1.5-3.5

SC2-5

SC4-8

SC4-12

SCHA5-12

SCHB5-12

Dia. mm

1.5-3.5

2-5

4-8

4-12

5-12

5-12

Cut length  mm

30-2000

30-6000

200-6000

200-6000

700-12000

700-9000

Cut error mm

+-1

+-1

+-1

+-1

+-10

+-10

Speed m/min

25

30

35

30

45

45

Straight motor kw

1.5

1.5

4

7.5

45

45

Cutting motor kw

0.75

0.75

3

4

4

4

Overall size M

1.7*0.4*0.8

1.2*0.4*0.9

7.3*0.6*1.2

8*0.8*1.3

2.1*0.7*1.3

1.9*0.6*1.4

Weight KG

130

150

650

1000

1200

900



 SC1.5-3.5

Automatic Wire straightening and cutting machine

SC2-5

Automatic Wire straightening and cutting machine

SC4-8

Automatic Wire straightening and cutting machine

SCHA5-12

Automatic Wire straightening and cutting machine

SCHB5-12

Automatic Wire straightening and cutting machine



 Main features

It is of high quality and high efficiency.It is also sample to operate.Meanswhile the machine can save material resources.





Director:Edson an

Mobile: 0086-15930180627 (whatsapp/viber)

Skype: dapu-machine

Wechat:edson652113



If you have any question ,you can contact me.

We are looking forward to cooperating with you.
