Johnson screen welding machine
- 3 Set / Sets per Month
- TIANJIN CHINA
- T/T
-
Denoh Gas And Oil Pipeline Welding Machine Factory Price Best Pipe Welding Machine
-
Automated Pipe Welding Systems Price Advantage Full Automatic Inner Welding Machine
-
Pe Pipe Welding Machine Factory Price Inner Ring Seam Welding Machine
-
Internal Welding Machine Pipeline Welder Tools Chinese Supplier
-
Full Automatic Inner Welding Machine Pipe Welding Equipment Moving Stablely
-
Pipeline Welder Tools New High Speed Full Automatic Inner Welding Machine
Product Details
| Condition: | New | Place of Origin: | Hebei, China | Brand Name: | JIAKE |
| Model Number: | JK-KSH | Tube Diameter: | 80-1200mm | Dimensions: | 9000mm x 1200mm x 2300mm |
| Weight: | 12000kg | Usage: | weld Johnson screen mesh | Voltage: | 380V |
| Power(W): | 5 KW | Certification: | ISO9001 | Warranty: | 12 month |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Johnson screen welding machine
Features:
The machine are combined by CD61100 lathe, welding control cabinet, transformer, roller and wire rolling unit. It has strongpoint of standard welding slot distance.
Usage: welding wire wrapped screen pipe, mineral filtrating mesh, coal washing mesh, water filtration mesh, water well screen etc.
Machine functions:
Machine’s working mode: Automatic mode and Adjustable mode
a). Automatic mode, input correct variable values then the machine will working in automatic cycle.
b). Adjustable mode, every parts movement could be adjustable.
Main parameters:
Model | φ50-200mm | φ100-400mm | φ400-1200mm |
Power | 3Phase 380V 50Hz | 3Phase 380V 50Hz | 3Phase 380V 50Hz |
Rated capacity | 100 KVA | 100 KVA | 100 KVA |
Slot distance | ≥0.1mm | ≥0.2mm | ≥0.25mm |
Canister length | ≤6000mm | ≤6000mm | ≤4000mm |
Weld material | Stainless Steel Wire & Low Carbon Steel Wire | ||
V-wire size | 1.8-5.0mm | 1.8-5.0mm | 1.8-5.0mm |
Support rod size | 1.8-5.0mm | 1.8-5.0mm | 1.8-5.0mm |
Overall dimension | 13000*1500*3300mm | 13000*1600*3400mm | 11000*2100*3800mm |
Weight | 10000KGS | 11000KGS | 13000KGS |
