Steel wire mesh welding machines JK-RM-2500B
Steel wire mesh welding machines characteristic:
1. Using range-For the manufacture of engineered mesh as well as standard reinforcing mesh in sheet. Both hot-rolled wire and cold-rolled wire are available by patented welding technology.
2. Welding system-Import pneumatic parts(such as cylinders),which are leader brands, ensure the welding speed, pressure and intensity, and ensure the action
accurately, environment adaptability and safety.
3. Patented technical welding circuit ensure the intensity while welding hot-rolled wire up to 12mm.
4. Line wire feeding system-Servo motor which ensure the mesh dimension and increasing the welding speed to increase the production which is up to
20 - 50 thousand tons every year.
Steel wire mesh welding machines main parameter:
model |
JK-RM-2500B |
JK-RM-3300B |
max mesh width (mm) |
2500 |
3300 |
line wire spacing (mm) |
≥ 100 Steplessly adjustable |
≥ 100 Steplessly adjustable |
cross wire spacing (mm) |
≥ 25 Steplessly adjustable |
≥ 25 Steplessly adjustable |
wire diameter (mm) |
5-12 |
5-12 |
max welding capacity (mm) |
12+12 |
12+12 |
max welding speed (row/min) |
40-60 |
40-60 |
numder of welding points (group) |
24 |
32 |
rated electrical power (KUA) |
150KVAX12 |
150KVAX16 |
air pressure (MPA) |
≥ 0.7 |
≥ 0.75 |
feeding method |
Bars |
Bars |
welding materials |
Hot-rolled and cold-rolled wire |
Hof-rolled and cold- rolled wire |
