Specifications
automatic stainless steel wire mesh welding machinefull automatic and high speed
easy to operate,stable function
CE
steel wire mesh welding machine
Advantage:
1.High stability, lowness noise, draws straight and sends wire automatically.
2.It can weld the wire mesh which has thick diameter
3.It has the board machine frame, electromagnetism stepless time, the distance of wire is wide, small noise, stabilization and save electricity, the mesh is standard.
Wire Feeding:
Both longitude wire and cross wire are fed from wire coils automatically.
Welding Material:
The machine can be used to weld low carbon steel wire, stainless steel wire mesh and other kinds of welded wire mesh.
Mesh Usage:
It is widely used for construction fence mesh, poultry cageand other areas.
wire mesh welding machine
automatic stainless steel wire mesh welding machine
JK-DNW-2
Model | JK-DNW-2 |
Mesh width | 1219.2mm,1524mm (4feet, 5feet) |
Aperture/Pitch | 12.7mm-101.6mm |
Wire Diameter | 0.65mm-1.8mm |
Voltage | 3-phase,380V,50Hz or according to client’s voltage |
Motor | 2.2KW |
Welding Speed | ≤120rows/min |
Measurement of Machine | 2.5m*1.3m*1.4m 2.9m*1.3m*1.4m |
Weight | 2.0T, 2.5T |
Welded Transformer Capacity | 60kva*4; 60kva*5 |
Other Models:
JK-DNW-1
Model | JK-DNW-1 |
Mesh width | 914.4mm,1000mm |
Aperture/Pitch | 6.35mm-12.7mm |
Wire Diameter | 0.4mm-0.65mm |
Voltage | 3-phase,380V,50Hz or according to client’s voltage |
Motor | 2.2KW |
Welding Speed | ≤75 rows/min |
Measurement of Machine | 2.3m*1.3m*1.4m |
Weight | 1.5T |
Welded Transformer Capacity | 50kva*3 |
JK-DNW-3
Model | JK-DNW-3 |
Mesh width | 1219.2mm,1524mm, 1828.8mm,2133.6mm (4feet,5feet,6feet,7feet) |
Aperture/Pitch | 25.4mm-101.6mm |
Wire Diameter | 1.0mm-2.2mm |
Voltage | 3-phase,380V,50Hz or according to client’s voltage |
Motor | 2.2KW,4.0KW |
Welding Speed | ≤80 rows/min |
Measurement of Machine | 2.5m*1.3m*1.4m 2.9m*1.3m*1.4m |
Weight | 2.0T, 2.5T,3.0T, 3.5T |
Welded Transformer Capacity | 60kva*4,60kva*5,60kva*6,60kva*7 |
wire mesh products
