Help CenterZinc Plating Automatic Steel Wire Mesh Welding Machine
Related Products
-
Hot Dip Galvanizing Wire Mesh Welding MachineUS$ 10,000 - 100,000MOQ: 1 Set -
Roll Mesh Welded Wire Mesh Welding Machine EuipmentUS$ 10,000 - 100,000MOQ: 1 Set
-
CNC Computer Automatic Galvanized Wire&low Carbon Steel Electric Welded Wire MeshmachineUS$ 15,000 - 24,000MOQ: 1 Set
-
High Quality Circuit Electric Welded Wire Mesh Machine Manufacture and SupplierUS$ 15,000 - 24,000MOQ: 1 Set
-
Automatic Security Fence Roll Welded Mesh Wire MachineUS$ 10,000 - 16,000MOQ: 1 Set
Specifications
Zinc plating automatic steel wire mesh welding machineautomatic
high speed
easy to operate
guarantee: 1 year
steel wire mesh welding machine
steel wire mesh welding machine
Description:
1.Both longitude wire and cross wire was fed from wire coils automatically.
2.It has advantages such as design reasonable, low noise, more stable, easier tooperatr.
3.The mesh size is precise and the machine can be set the width and length according to customer's requirement.
steel wire mesh welding machine
Technical Parameter:
Model |
JK-DNW-1 |
JK-DNW-2 |
JK-DNW-3 |
Mesh width |
914.4mm,1000mm |
1219.2mm,1524mm (4feet, 5feet) |
1219.2mm,1524mm, 1828.8mm,2133.6mm (4feet,5feet,6feet,7feet) |
Aperture/Pitch |
6.35mm-12.7mm |
12.7mm-101.6mm |
25.4mm-101.6mm |
Wire Diameter |
0.4mm-0.65mm |
0.65mm-1.8mm |
1.0mm-2.2mm |
Voltage |
3-phase,380V,50Hz or according to client’s voltage |
||
Motor |
2.2KW |
2.2KW |
2.2KW,4.0KW |
Welding Speed |
≤75 rows/min |
≤120rows/min |
≤80 rows/min |
Measurement of Machine |
2.3m*1.3m*1.4m |
2.5m*1.3m*1.4m 2.9m*1.3m*1.4m |
2.5m*1.3m*1.4m 2.9m*1.3m*1.4m |
Weight |
1.5T |
2.0T, 2.5T |
2.0T, 2.5T,3.0T, 3.5T |
Welded Transformer Capacity |
50kva*3 |
60kva*4; 60kva*5 |
60kva*4,60kva*5,60kva |
Zinc plating automatic steel wire mesh welding machine
The application of product:
It is widely used for construction mesh and poultry cage.
