Specifications
2014 New type electric wire mesh welding machinehigh automatic
stable function
easy to operate
guarantee period: 1 year
2014 New type electric wire mesh welding machine
Function Characteristics:
High efficiency,low noise and power consumption,accurate mesh opening size more stable, easier to operate.It is made up of main welding machine, electrical control cabinet, repairing table, repairing machine, bracket for longitude wires, wire rolling machine and plastic rollers.
Wire Feeding:
Both longitude wire and cross wire are fed from wire coils automatically.
Advantages:
The mesh size is precise and the machine can set the width of length according to customers’ requirements.
Welding Material:
The machine can be used to weld low carbon steel wire, stainless steel wire mesh and other kinds of welded wire mesh.
2014 New type electric wire mesh welding machine
Model | JK-DNW-1 |
Mesh width | 914.4mm,1000mm |
Aperture/Pitch | 6.35mm-12.7mm |
Wire Diameter | 0.4mm-0.65mm |
Voltage | 3-phase,380V,50Hz or according to client’s voltage |
Motor | 2.2KW |
Welding Speed | ≤75 rows/min |
Measurement of Machine | 2.3m*1.3m*1.4m |
Weight | 1.5T |
Welded Transformer Capacity | 50kva*3 |
Other Models:
Model | JK-DNW-2 |
Mesh width | 1219.2mm,1524mm (4feet, 5feet) |
Aperture/Pitch | 12.7mm-101.6mm |
Wire Diameter | 0.65mm-1.8mm |
Voltage | 3-phase,380V,50Hz or according to client’s voltage |
Motor | 2.2KW |
Welding Speed | ≤120rows/min |
Measurement of Machine | 2.5m*1.3m*1.4m 2.9m*1.3m*1.4m |
Weight | 2.0T, 2.5T |
Welded Transformer Capacity | 60kva*4; 60kva*5 |
Model | JK-DNW-3 |
Mesh width | 1219.2mm,1524mm, 1828.8mm,2133.6mm (4feet,5feet,6feet,7feet) |
Aperture/Pitch | 25.4mm-101.6mm |
Wire Diameter | 1.0mm-2.2mm |
Voltage | 3-phase,380V,50Hz or according to client’s voltage |
Motor | 2.2KW,4.0KW |
Welding Speed | ≤80 rows/min |
Measurement of Machine | 2.5m*1.3m*1.4m 2.9m*1.3m*1.4m |
Weight | 2.0T, 2.5T,3.0T, 3.5T |
Welded Transformer Capacity | 60kva*4,60kva*5,60kva*6,60kva*7 |
2014 New type electric wire mesh welding machine
Use of mesh sheet:
It is widely used for construction mesh and poultry cage.
2014 New type electric wire mesh welding machine
We can offer installation and training the workers for you.Our guarantee time is one year since the machine was installed at the buyer's factory but within 18 months against B/L date.
We can customize the fence mesh welding machines, reinforcing mesh welding machine, animal cage mesh welding machine, wire mesh welding machine, welded wire mesh machine.
