Automatic Feeding Electric Welded Mesh Machine in Rolls Useing to Make Animal Cage

Automatic Feeding Electric Welded Mesh Machine in Rolls Useing to Make Animal Cage photo-1
US$ 10,000 - 18,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
JIAKE
Model Number:
DPW2
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Brand Name JIAKE
Model Number DPW2
Primary Voltage 380V
Rated Duty Cycle 50%
Rated Capacity 60kva*4
Dimensions 2.3M*1.3M*1.4M
Usage welding low carbon steel wire
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Automatic feeding electric welded mesh machine in rolls
wire dia:0.65-2.2mm
mesh hole:1/2''-4''
Mesh width:Max.2M

 Automatic feeding electric welded mesh machine in rolls useing to make animal cage

1.Description of electric welded mesh machine



1. Both longitude wire and cross wire was feeding from wire coils automatically



2.The raw material is applicable for low-carbon steel wire or stainless steel wire



3.It has advantage of reasonale design,low erengy using and adjust speed convenitent



4.The mesh size can be set into control carbinet,computer and PLC control technique



5 Its made up of main welding machine, electric control cabinet, repairing table,repairing table,repairing machine ,bracket for longitude wire,wire rolling machine and plastic rollers.



2.Technical parameter of electric welded mesh machine



mesh width

1219.2mm/1500mm/

1524mm/2000mm

Mesh aperture

12.7-101.6mm

wure diameter 0.65-1.8mm/1-2.2mm voltage 380V
motor 2.2kw welding speed Max.120rows/min
weight 2.0-2.5T welding transformer 60KVA*4-5.



electric welded mesh machine in rolls
Automatic feeding electric welded mesh machine in rolls useing to make animal cageAutomatic feeding electric welded mesh machine in rolls useing to make animal cageAutomatic feeding electric welded mesh machine in rolls useing to make animal cage



finished rolling mesh



Automatic feeding electric welded mesh machine in rolls useing to make animal cage
