Strong Qualtiy Building roll galvanized welded wire mesh machine
- 30 Set / Sets per Month
- Xingang China
- T/T
- AC spot welding machine 25KVA Iron sheet spot welding machine
- AC spot welding machine 35KW Iron sheet spot welding machine
- AC spot welding machine Resistance spot welding machine Iron sheet spot welding machine
- Heavy Duty Gantry Resistance Welding System Integration for Steel Bars Mesh
- Wire heating mesh resistance welding machine pneumatic pressurized spot welding machine
- Large-scale welding machine Chicken wire automatic welding spot welder Resistance welding equipment
Product Details
Place of Origin: | Hebei, China | Brand Name: | JIAKE | Model Number: | DPW2 |
Primary Voltage: | 380V | Rated Duty Cycle: | 50% | Rated Capacity: | 60KVA*4-5 |
Dimensions: | 2.5M*1.3M*1.4M | Usage: | welding low carbon steel wire | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Building roll galvanized welded wire mesh machinewire diameter:0.65-2.2mm
mesh hole:6.35mm/12.7mm/,25.4mm/50.8mm/101.6mm
CE
Building roll galvanized welded wire mesh machine
Building roll galvanized welded wire mesh machine
Main function
The electric welded wire mesh machine adopts computer and PLC control technique,both longitude wire and cross wire was feeding from wire coils automatically.the raw material is applicable for low-carbon steel wire or stainless steel wire.the mesh size is precise and machine can be set the width of length according to customers' requipment.
Main parameter
the welding speed can reach 120 rows per minute
Guarantee time
1years after install but should be within 18 months of theB/L date
mesh hole(mm) | Width (mm) | Wire Diameter (mm) | Production Length per Roll (mm) | Welded Speed | Energy Consumption | Overall Dimension(mm) |
12.7-101.6 (1/2"-4") | 914.4-1219.2 | Dia.0.63-Dia.2 | 120 (400') | 90-120 | 380V | 2600x1700x1350 |
Mesh hloe (mm) | Width (mm) | Wire Diameter (mm) | Production Length per Roll (mm) | Welded Speed | Energy Consumption | Overall Dimension(mm) |
25.4-152.4 (1"-6") | 1219.2,1524,1828.8 | Dia.1.07-Dia.2 | 91.4m (300') | 50-80 | 380V; | 3350x1800x1400 |
Mesh hole (mm) | Width (mm) | Wire Diameter (mm) | Production Length per Roll (mm) | Welded Speed | Energy Consumption | Overall Dimension(mm) |
6.35-12.7 (1/4"-1/2") | 1219.2-1828.8 (48"-60") | Dia.0.74-Dia.1.07 | 120m (400') | 70-100 | 380V; | 3050x1900x1750 |
Mesh hole (mm) | Width (mm) | Wire Diameter (mm) | Production Length per Roll (mm) | Welded Speed | Energy Consumption | Overall Dimension(mm) |
6.35-12.7 (1/4"-1/2") | 914.4-1219.2 (12"-48") | Dia.0.45-Dia.1.07 | 120m (400') | 90-120 | 380V; | 2350x1820x1700 |
