GI barbed wire machines| pvc barbed wire machines made in China
- 20 Set / Sets per Month
- xingang
- T/T
You May Like
-
automatic straight and reverse twisted Barbed wire making machine JIAKE FACTORY
-
galvanized barbed wire machine/barbed wire making machine(Direct factory)
-
galvanized barbed wire weaving machine factory
-
normal double twisted barbed wire machine made in china
-
double strand barbed wire making machine(normal twisted, reverse twisted)
-
razor barbed wire mesh making machine (factory)
Product Details
| Place of Origin | Hebei, China | Brand Name | JIAKE | |
| Model Number | CS-A B C | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
strand wire diameter: 2.2-3.0mmbarbed wire diameter:1.8-2.2mm
CS-A type Barbed Wire Machine
The materials used are general hot-dipped galvanized low carbon steel wire and plastic coated wire. The products are widely used in
national defense, railway, highway, agriculture, animal husbandry and other industries.
Main parameters:
No. | Item | Units | Parameters |
1 | Motor power | KW | 3 |
2 | Main drive shaft speed | r/min | 402 |
3 | Strand wire diameter | mm | 2.2-3.0 |
4 | Barbed wire diameter | mm | 1.8-2.2 |
5 | Barb distance | Mm | 76(3”) 102(4”) 127(5”) |
6 | Twist number | Pcs | 3.5 |
7 | Theoretical output | Kg/h | 70 |
8 | Total weight | Kg | 1200 |
9 | Dimension of main part | mm | 1950*950*1300 |
10 | Dimension of take-twisting part | mm | 1760*550*760 |
Note: Special specification models can be customized according to customer requirements.
CS-B type Single Strand Barbed Wire Machine
The materials used are general hot-dipped galvanized low carbon steel wire and low-strength steel wire. Main feature: saving materials.
Main parameters:
No. | Item | Units | Parameters |
1 | Motor power | KW | 2.2 |
2 | Main drive shaft speed | r/min | 355 |
3 | Strand wire diameter | mm | 2.2-3.0 |
4 | Barbed wire diameter | mm | 1.8-2.2 |
5 | Barb distance | Mm | 102(4”) 127(5”) |
6 | Theoretical output | Kg/h | 40 |
7 | Total weight | Kg | 1000 |
8 | Dimension | mm | 3100*1000*1150 |
Note: Special specification models can be customized according to customer requirements.
CS-C type Straight and Reverse Twisted Barbed Wire Machine
The materials used are general hot-dipped galvanized low carbon steel wire and low-strength steel wire, using straight and reverse twist way for winded the twist. The barbed wire
products has no rebound and winding phenomenon, so it is more beautiful compared with ordinary
barbed wire.
Main parameters:
No. | Item | Units | Parameters |
1 | Motor power | KW | 2.2 |
2 | Main drive shaft speed | r/min | 355 |
3 | Strand wire diameter | mm | 1.6-2.8 |
4 | Barbed wire diameter | mm | 1.6-2.2 |
5 | Barb distance | Mm | 102(4”) 127(5”) |
6 | Twist number | Pcs | 7 |
7 | Theoretical output | Kg/h | 40 |
8 | Total weight | Kg | 1000 |
9 | Dimension | mm | 3000*1000*1150 |
Note: Special specification models can be customized according to customer requirements.
