Specifications
Our factory can supply 2 kinds of chicken cage welding machines--pneumatic type and mechanical type
Automatic Chicken Cage Mesh Welding Machine
Our factory can supply 2 kinds of chicken cage welding machines——pneumatic type and mechanical type. The machines can also be used to weld other animal cages, like rabbit cages, pet cages, poultry cages etc
Automatic chicken cage mesh welding machine (pneumatic type)
Automatic chicken cage mesh welding machine (machine characteristics)
1. The machine adopts air cylinder pulling mesh, air cylinder welding mesh, air cylinder cut edge, air cylinder cut mesh and the mesh aperture is accurate. (Full automatic)
2. The longitude wires are feeding from coils. The cross wires are feeding from coils.
3. The cross wires are fed by servo motor automatically from coils. It can feed different length of cross wires in same mesh sheet to reserve the designed mesh hole.
4. The machine is controlled by PLC program&Touch screen and it’s very easy to operate.
5. The machine is the most advanced machine for chicken cage.
Automatic chicken cage mesh welding machine (technical parameters)
Wire Diameter | 2-3.5mm | Width of Mesh | 1200mm |
Longitude Wire Space | 50-200mm | Cross Wire Space | 25-200mm |
Welding Electrodes | 16 pcs | Welding Speed | 45 times/min |
Longitude Wire Feeding | From wire coils | Cross Wire Feeding | From wire coils |
Rated Electrical Power | 60kva*2 pcs | Rated Voltage | According to buyers’ voltage |
Overall Size | 5.5*2.1*1.5mm | Weight | 2500kg |
Automatic chicken cage mesh welding machine (mechanical type)
Automatic chicken cage mesh welding machine (machine characteristics)
1. The longitude wires are fed from coils. The cross wires are fed from coils while the diameter of cross wire is 1.8-2.5mm. Also the cross wires should be pre-straightened and pre-cut when the diameter of cross wire is 2.6-3.0mm.
2. The machine is equipped with precise equipment for weft cutting positioning, so the length of wefts is identical and regular, it is unnecessary to slice the side.
3. Mesh pulling system adopts elastic tension and opening positioning mesh, it is easy to regulate mesh hole, and mesh opening size is rather accurate, welding aperture could adjust randomly within range.
4. Not only welding speed is fast, it is easy to learn and operate. Only one worker can finish the operation.
Automatic chicken cage mesh welding machine (technical parameters)
Wire Diameter | 1.8-3mm | Width of Mesh | 1200mm |
Longitude Wire Space | 50-200mm | Cross Wire Space | 25-200mm |
Welding Electrodes | 16 pcs | Welding Speed | 60 times/min |
Longitude Wire Feeding | From wire coils | Cross Wire Feeding | Dia.1.8-2.5mm From wire coils; Dia.2.6-3.0mm Should be pre-cut |
Rated Electrical Power | 60kva*2 pcs | Rated Voltage | According to buyers' voltage |
Overall Size | 2.5*2.1*1.4m | Weight | 2500kg |
Accessorial Parts: Repairing mesh machine; Electric control cabinet; Wire plate(16 pcs); Electric scissors(2 pcs)
After-sales service:1.We offer installation and train the workers for the customers.
2.Guarantee time:one year since the machine was installed at buyer's factory but within 18 months against B/L date.
3. We can help design the layout of the machine placed in the factory.
We can customize the fence mesh welding machines, reinforcing mesh welding machine, animal cage mesh welding machine, wire mesh welding machine, welded wire mesh machine, chain link fence machine, hexagonal wire netting machine, gabion mesh machine, stone mesh machine, expanded metal mesh machine, barbed wire machine, razor barbed wire machine and so on, please do not hesitate to contact us.
Contact: Daisy Lee
Hebei Jiake Welding Equipment Co.,Ltd
Mobile: :+86-318-15324391556
Fax:+86-0318-7565522
Skype:qq1815361000
