Goods Description of CW61128 Universal Lathe Machine
This machine tool is a universal general lathe, suitable for high speed steel and hard alloy cutter shaft parts of different materials, the cylinder type and disk parts, for turning Cylindrical ,end, grooving and cutting cone inside car, boring, all kinds of screw thread and other processes.
Main shaft adopts three supporting structure, form a box, make the bed has higher stiffness. Machine equipped with single pump, forced lubrication, and slip board, the tool post, saddle, tail frame can move quickly.
OUR OUTSTANDING ACHIEVEMENTS
MORE DETAILS
Main Features of CW61128 Universal Lathe Machine
1. Lathe structure stiffness and transmission stiffness were higher, the accuracy, stability and able to strong cutting;
2. Bed guide glide surface using TSF wear-resisting panel structure, sports portable agile, long life;
3. Spindle and positive &negative switching and brake using hydraulic control;
4. The bed with pressure oil forced lubrication, cooling unit using water and electricity separation.
Technical parameters of CW61128 Universal Lathe Machine
| MODEL | CW61128 | CW61148 | CW61168 | CW61198 | CW61208 |
| Max.weight of workpiece | 10000kg | ||||
| Max.swing over bed | 1280mm | 1480mm | 1680mm | 1980mm | 2080mm |
| Max.swing over cross slide | 800mm | 1000mm | 1200mm | 1500mm | 1600mm |
| Center distance | 2m,3m,4m,5m,6m,8m,10m,12m | ||||
| Max swing over gap | 1580mm | 1780mm | 1980mm | 2280mm | 2380mm |
| Valid length of gap | 600mm | ||||
| Bed width | 1100mm | ||||
| HEAD STOCK | |||||
| Spindle hole | Φ130mm | ||||
| Spindle taper | 140# | ||||
| Spindle speeds | 3.15-315r/min or 2.5-250r/min | ||||
| GEAR BoX-THREADS&FEEDS | |||||
| Metric threads range(kinds ) | 44 1-120mm | ||||
| Inch threads range(kinds) | 31 1/4-24 | ||||
| Moudle threads range(kinds) | 45 0.5-60mm | ||||
| Diametral threads range(kinds) | 38 1/2-56DP | ||||
| Longitudinal feeds range(kinds) | 56 0.1-12mm | ||||
| Cross feed range(kinds) | 56 0.05-6mm | ||||
| Rapid feed:Long/Cross | 3400mm/min, 1700mm/min | ||||
| TOOL-POST | |||||
| Distance between Center & Tool | 48mm | ||||
| Tool section | 45*45mm | ||||
| CARRIAGE | |||||
| Cross slide travel | 860mm | ||||
| Compound rest travel | 280mm | ||||
| TAILSTOCK | |||||
| Sleeve diameter | Φ260mm | ||||
| Sleeve taper | 80# | ||||
| Sleeve travel | 300mm | ||||
| MOTOR | |||||
| Main motor | 30KW | ||||
| Coolant motor | 0.15KW | ||||
| Rapid feed motor | 1.5KW | ||||
| Tailstock motor | 1.5KW | ||||
AFTER SERVICE TEAM IN SOUTHEAST ASIA
Our company
Why choose us?
1.Your inquiry will be replied in 24 hours.
2.Our factory is more industry technology experience for 20 years .
3.To offer free spare parts and service within one year of warranty.
4.Technology Support Provide operation video for training.
5.Professional after-sales service team.
6.Give reasonable offers with the best quality.
