Lighting Protection PV Combiner Box, 8-in,1-out

1. Simple Introduction of PV Combiner Box, 8-in,1-out

PV Lighting Protection Combiner Box is used for the link of PV inverter and PV array to lessen the cable for the connecting, easy to maintain and improve the reliability. We always fix the DC convergence device between the PV inverter and PV array. It is the supporting components of our PV inverter for the PV power generating. You could connect a certain number of PV components in series to be the PV array according to the voltage range of DC input; then, connect the PV array to PV lighting protection combiner box for the converge, through the output of lightning protection device and breaker, it is easy for switching-in of PV inverter and improve the system safety and lessen the installing time.

The combiner box has current counter-attack,over current,over voltage function and lighting protection as well.

Customized design possible.

2.Main parameters of PV Combiner Box:

1). IP65, waterproof, dustproof, rust prevention, meet the requirement of outdoor installation.

2). Wide DC input voltage range, Max.open circuit voltage reaches 1000VDC.

3). PV dedicated DC fuse.

4). PV dedicated high-voltage SPD, both positive and negative have lightning protection function.

5). Use the four pole breaker of positive and negative respectively in series to improve DC withstand voltage.

6). Multi-choice : 6/8/12/16/24 etc., and can be personalized according to user needs.

7). Nylon cable waterproof connectors and MC4 connectors two ways of input can be optional.

3.Technical Parameters:
