T100G-3 100HP Small Track Bulldozer
Application:
Refuse land or similar wet earth land places.
T100G-3 bulldozer features:
1.Engine: choose the pressure rising engine produced by British Ricardo joint-venture technology, lower oil consumption, stronger torsion.
2.Main clutch: choose dry, dual-sheet and constant combining clutch, which features simple construction, more reliable, and easier maintenance.
3.Gearbox: choose 4F+2R mechanical gearbox, which is of high efficiency, simple operation, easy maintenance and reliable operation.
4.Turning clutch: choose dry and multi-piece turning clutch, manually operating with hydraulic pressure, easily maintaining, lightly and conveniently operating.
5.Transmission: choose two classes, straight teeth, big modulus gear transmission, stronger carrying capacity, and higher in reliability.
6.Optional device: several devices such as direct-pouring shovel, environmentally hygienic, angle shovel, coal pushed shovel and soil scarifier are available for user.
Model |
Unit |
T100G-3 |
Total weight |
kg |
10400 |
Max. towing force |
kN |
95 |
Engine model |
/ |
LR6A3-23 |
Engine rated power/speed |
kw/r/min |
81/2300 |
Fuel consumption of engine |
g/km.h |
≤242 |
Forward travel speed |
km/h |
1st/2nd/3rd/4th: 2.6/3.9/6.7/10.4 |
Backward travel speed |
km/h |
1st/2nd: 3.7/6.7 |
Width of track shoes |
mm |
450 |
Land pressure |
kpa |
54.4 |
Overall L*W*H |
mm |
4190*2935*3020 |
Dozer W*H |
mm |
2935*960 |
Blade max lifting height |
mm |
830 |
Blade max digging depth |
mm |
350 |
Twing equipment/scarifier(optional) |
/ |
swing type/3-shank |
We grants our clients a 12 month period or 2000 hours warranty for any machine purchased from us.
During the warranty period,In case the defect of material,design,making,assembly or workmanship has occurred with spare parts in normal operation according to the machine manual.
The defective part will be repaired or replaced free of charge at our discretion.
1) We help customer to choose suitable machine.If you visit us,we can give on-site technical consultation, driver training and
maintenance training in our factory.
2) We make driving test before leaving factory,That makes sure our client use the machine normally.customer will receive machine as “0”hour all new condition.
3) We'll supervising goods ship in to container & take photos for customer.Our powerful shipping agency will offer
best sea freight fee and responsible for detail treatment to goods.
4) Operation manual in English provided.If you need other language manual,we can provide you based on adding
little cost.
5) We prepare free spare parts in a toolbox for customer for emergency use.
6) We make record for every machine chassis no.and tracing them to get the latest information about the machine.
And give the best service timely.
7) Exclude the guarantee period, you can buy parts from us at moderate cost price. We promise support service for
the machine till it reject.
