5 Micron Filters RFB-400* Check Valve Magnetic Return Filter For Oil Filter Machine

5 Micron Filters RFB-400* Check Valve Magnetic Return Filter For Oil Filter Machine thumbnail-1
5 Micron Filters RFB-400* Check Valve Magnetic Return Filter For Oil Filter Machine thumbnail-2
5 Micron Filters RFB-400* Check Valve Magnetic Return Filter For Oil Filter Machine photo-1
5 Micron Filters RFB-400* Check Valve Magnetic Return Filter For Oil Filter Machine photo-2
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Return Filter
Structure:
Cartridge
Contact Supplier Request Quote Chat Now
Xinxiang Dongfeng Filter Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai Ningbo Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Return Filter
Structure Cartridge
Place of Origin Henan, China
Brand Name DFFILTRI
Model Number Hydraulic Filter
Power(W) Needed
Weight 14.7kg
Dimension(L*W*H) Stardard
Certification ISO9001:2008
Warranty 6 Months
After-sales Service Provided Overseas service center available
Product Description
Application
Hydraulic System
Filtration Rating(um)
3,5,10,20,30....
Weight(kg)
14.7
Brand
DFFILTRI
Housing Material
Cast Aluminum, Carbon Steel
Model
RFB-400*5-F-H
Seals
Perbunan(=NBR)
Warranty
one year
Type of Connection
Flanged Connection
Function
hydraulic filter filtrate oil
Nominal Flow Rate(L/min)
400
MOQ
5 Piece
Dia(mm)
80
Price
5-20 PCS USD 20.00
Nominal Pressure
16
Port
Ningbo/Shanghai/Qingdao

Introduction:

RFB-series filters are used in the return line of hydraulic systems. They can be installed on the top at the side or in the bottom of tanks. Every filter is equiped with apermanent magnet to remove ferrous matters in the oil.Filter element is made of no woven fibre with high efficiency and low restriction. A diffuse is fitted in the lower part of the filter, ensuring steady oil flow out from into the tank. There is a check valve in the filter to prevent oil flowing out from the tank when filter element is changed.
The differential pressure indicator will signal when the pressure drop across filter element attains 0.35MPa and the by-pass valve opens at 0.4MPa.


Detailed Images
Other Products
Our Company

Xinxiang Dongfeng Filtration Technology Co., Ltd. was founded in the 1994, the registered capital reaches 50 million Yuan, and DFFILTRI is the leading enterprise in the well-known" Township of Filter-Xinxiang".The company was elected "Vice-chairman Unit " by filtration & separation industry association in 2006. At present , has formed four series leading products, they are "Hydraulic System Cleaning & Filtration Device","Complete Hydraulic Filters", "Hydraulic System Accessories", "Pump Valve Components".

Packing & Delivery
Our most professional packaging
Transport of large trucks to the seaport
And international transport cooperation
Our Service

1. OEM Manufacturing welcome: Product, Package...
2. Sample order
3. We will reply you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the
goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer
the solve way for you.

FAQ

Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 100% before delivery. We'll show you the photos of the products and packages
before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR.

Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.

Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock.

Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
