GU-H-25x20-F-P Hydraulic Pressure Line Filter with Top Cover and Spin-on Housing

Specifications

GU-H Check Valve Pressure line Filters
1.7-30 working days prompt delivery
2.High Filtration Ratio
3.Competitive price

                        GU-H-25x20-F-P Hydraulic Pressure Line Filter with Top Cover and Spin-on Housing

1. Product introduction

GU-H series filter is installed in the pressure pipeline of hydraulic system, used to clear away or prevent the pollutants invading generated in the hydraulic oil, prevent valve core stuck, throttling the small holes, cracks and damp holes blocking, and excessive wear of hydraulic components etc. failures happening; This series of filter is equipped with the bypass valve and check valve, accordingly have the dual protection, also with differential pressure indicator, when the element is clogged to oil inlet/outlet and pressure difference reaches 3.5bar, the signal is sent out, the filter element should be cleaned or replaced.



2. Product characteristics

Filter basic construction

GU-H series filter is composed of the top cover and spin-on housing.



2.1 Housing material

Top cover material: Ductile cast iron
Filter bowl material: Carbon steel



2.2 Seals

Perbunan (=NBR) (-30~+120°C);  Viton=FPM(-20~+200°C)

2.3 Filter element

Filter medium material

High strength carbon steel skeleton



2.4 Optional accessories

Electric clogging indicator: CS-V
By-pass valve(setting 4bar)



2.5 Type of connection (chosen according to the filter type)

Metric thread connection;  Flanged connection



2.6 Symbols



3. Type selection and technical data

3.1 Order example



3.2 Technical Data



4. Mounting Size

4.1 Threaded connection

4.2 Flangede connection



5.  Product characteristic curves

The total filter assembly pressure drop is the sum of housing and element pressure drop,filter selection calculated as per the following curves.

5.1 Housing pressure drop / flow rate characteristic curves

Housing pressure drop /flow rate characteristic curves are according to ISO3968, and suitable for the mineral oil with density 0.86 kg/dm³ and kinematic viscosity 30 mm²/s.





5.2 Differential pressure / flow characteristic curves of filter element

The characteristic curves of filter element are suitable for the mineral oil with kinematic viscosity 30 mm²/s. Differential pressure and viscosity is proportional.

     Note: If any other requriements, please consult us.
