50m Meter Laser Distance Meter
US$ 38 - 48
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
SYLAVAL
Model Number:
SW-60
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TTS210 Optical Total StationUS$ 2,000 - 3,000MOQ: 1 Piece -
TTS210R/501R High Performance Non Prism Total StationUS$ 2,000 - 3,000MOQ: 1 Piece
-
Laser Digital Level DL160US$ 30 - 60MOQ: 10 Sets
-
Laser Spirit Level DL160US$ 30 - 60MOQ: 10 Sets
-
G3 China Made Electronic Level Instrument With Best PriceUS$ 100 - 120MOQ: 10 Sets
Place of Origin
Jiangsu, China
Brand Name
SYLAVAL
Model Number
SW-60
Size
123*54*28mm
Measurement Accuracy
1mm
Measurement Range
0-60m
Specifications
50m Meter Laser Distance Meter50m Meter Laser Distance Meter
Product Description
Function:
Measure distance directly
Area Measurement
Volume Measurement
High accuracy
Quick measurement of distance area and volume
Continuous measurement
Additiong and Subtraction function
Max and Min value display
Switchable among m in ft
Auto power off
Instrument maintenancetions: The meter should not be stored in high temperature and strong humidity environment for long-term; if not used for long time, please take out the battery and place the meter in the allocated potable bag and store in cool and dry place. Please keep the device surface cleaning. Wet soft cloth is applied to clean dust, but erosion liquid is never allowed to use for the meter maintenance. Laser output window and its focus lens can be maintained according to maintenance procedures for optical device.
Tips:
During operation, tip information may appear on the main display screen as follows:
Err1:
Signal too weak
Measure target locations which are with stronger reflecting capability
Err2:
Signal too strong
Measure target locations which are weaker reflecting capability
Err3:
Battery voltage is too low
Replace battery
Err4:
Beyond working temperature
Carry out measurement with the meter in the specified scope
Err5:
Improper Measurement on Pythagorean proposition
Re-measure, and ensure the length of hypotenuse is longer than that of right-side
Err6:
Memory damage
Please contact the supplier
Measure distance directly
Area Measurement
Volume Measurement
High accuracy
Quick measurement of distance area and volume
Continuous measurement
Additiong and Subtraction function
Max and Min value display
Switchable among m in ft
Auto power off
Instrument maintenancetions: The meter should not be stored in high temperature and strong humidity environment for long-term; if not used for long time, please take out the battery and place the meter in the allocated potable bag and store in cool and dry place. Please keep the device surface cleaning. Wet soft cloth is applied to clean dust, but erosion liquid is never allowed to use for the meter maintenance. Laser output window and its focus lens can be maintained according to maintenance procedures for optical device.
Tips:
During operation, tip information may appear on the main display screen as follows:
Err1:
Signal too weak
Measure target locations which are with stronger reflecting capability
Err2:
Signal too strong
Measure target locations which are weaker reflecting capability
Err3:
Battery voltage is too low
Replace battery
Err4:
Beyond working temperature
Carry out measurement with the meter in the specified scope
Err5:
Improper Measurement on Pythagorean proposition
Re-measure, and ensure the length of hypotenuse is longer than that of right-side
Err6:
Memory damage
Please contact the supplier
For more details, please refer to our website or our general catalogue.
| Medel | SF-60 | SF-100 |
| Measuring Range | 60m | 100m |
| Measuring Accuracy | ±2mm | |
| Measuring Unit | mm/in/ft | |
| Continuous Measurement | Yes | |
| Area Measurement | Yes | |
| Volume Measurement | Yes | |
| Indirect Measurement | The complete model | |
| Addition/Subtraction | Yes | |
| Max/Min Measurement | Yes | |
| Max storage | 20Unit | 30Unit |
| Backlight | Yes | |
| Key Sound Prompt | Yes | |
| Laser Level | 11 | |
| Laser Class | 635mm,<1mW | |
| Automatic laser off | 20s | |
| Automatic shutdown | 150s | |
| Storage Temperature | -20°C- 60°C | |
| Operating Temperature | 0°C- 40°C | |
| Storage Humidity | RH85% | |
| Power Supply | 1.5V 3•AAA | |
| Weight(Including Battery) | 180g | |
| Size | 123*54*28mm | |
