Home > Instruments & Meters > Optical Lens & Instrument > Rangefinder > Automatic Laser Distance Sensor Low Price
Automatic Laser Distance Sensor Low Price
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
AIGER
Model Number:
ZYT-0040
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin&Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Semiconductor Laser Range Measurement DetectorNegotiableMOQ: 1 Set -
Pricision Laser Distance Measurement DetectorNegotiableMOQ: 1 Set
-
High Temperature Laser Ranging SensorNegotiableMOQ: 1 Set
-
Low Price Laser Digital Range FinderNegotiableMOQ: 1 Set
-
Indsutrial Laser Distance Measuring DeviceNegotiableMOQ: 1 Set
Place of Origin
Beijing, China
Brand Name
AIGER
Model Number
ZYT-0040
Size
195 * 55 * 115mm
Measurement Accuracy
± 1mm
Measurement Range
0.1 ~ 30m of any surface,30 ~ 150m need to add reflectors
Specifications
1.Measurement accuracy:1mm2.Patented special design
3.Competitive price laser level
4.Excellent quality and service
Product Description
The Automatic laser leveling instrument which uses laser to measure the phase comparison method, can be measured without contacting with the surface or the reflective target surface.
The product structure design is reasonable, with adjustable mounting bracket, purge the lens unit, and air cooling device. It is suitable for industrial applications, especially for high-precision, and non-direct contact applications, such as crane operation locate and metallurgical production line control and so on.
Advantages
- Mm level measurement accuracy
- Continuous detection of a moving object
- For high temperature/dusty environment
- Precision-heavy-no need to reflect board
- With regional test ,control system and numeration function
Buying Guides
ZYT-0040-1 10Hz RS232/RS422
ZYT-0040-2 50Hz RS232/RS422
Technical Parameters
- Accuracy: ± 1mm
- Resolution rate: 0.1mm
- Repeatability: 0.5mm
- Measuring distance: 0.1 ~ 30m of any surface
30 ~ 150m need to add reflectors - Supply voltage: 10 ~ 24VDC
- Power consumption: 1W
- Laser Level: 650nm visible red
- 2 levels of security laser≤ 1mW
- Switch capacity: alarm output
- Simulation volume: 4 ~ 20Ma
- Protection class: IP65
- Dimensions: 195 × 55 × 115mm
- Housing: Aluminum
- Life: more than 50,000 h
- Weight: 2.5kg
Detailed Images
Application Range
Company Information
- Established in 1998
- National high-tech enterprises
- Excellent professional team
- Advanced water treatment technology
- Located in Beijing International Information Industry Base
- 120 persons, R&D staff account for 50%. Including 2 Ph.D, 9 Master and 15 senior technical engineers.
Please let us know your detailed requirements, we would like to choose the suitable model filter and give you the best solution!
Welcome your inquiry and further cooperation!
