Eco-friendly Car

Adopt 160 stamping channel steel, the leaf spring externally spans the chassis, and the auto beam is manufactured by steel for better load capacity and a more stable and safer drive; with the guarantee that the chassis is the most reliable one among like products, which lowers the frame damage rate largely. Adopt stamping integrative lumber-core container, which adopts cathode electrophoresis coating with good processing, no rust and more reliable performance. The platform development of vehicle models has strong seriation and popularity and guarantees the stable quality and quick service. Enlarge the automobile steel welding fore vertical beam with butt welding of the channel steel which promotes stronger bearing capacity and stability and can bear additional impact of 2 tons or more compared with other products. The whole vehicle is sprayed by cathode electrophoresis painting technology in order to be more reliable and make sure there’s no rust due to metallic paint, which promotes the vehicle to be more valuable. The vehicle has a horizontal type large oil tank and long life mileage and installed a 1.7-meter wide container. The whole vehicle with reasonable and compact match has stronger practicability. The ATX vehicle body adopts GOA core technology and widen Pillar B of the vehicle door in order to be safer.



SPECIFICATION

Model	Specification	Parameter
2B22104	loading capacity	1.5tons
	Overall dimensions of vehicle (mm)	3720*1400*1720
	dimensions of the cargo (mm)	2200*1400*700
	wheel base (mm)	1180
	wheel track   (back) (mm)	1220
	steel spring number)	13(7+6)
	width of   cabin(mm)	1100
	rated power (Hp)	13.2
	Displacement ( L)	0.996
	curb weight( kg)	930
	max speed	50
	engine	1105
	tire size (F/R)	Front:4.50-14
		Rear :6.00-16
	brake system	hydraulic system
	gear box	3+1
	brake system	foot brake; hand brake
	rear axle	3+1
	dump equipment	Yes
	Qty in 40hq (units)	SKD ,15units
	color	red





Model	Specification	parameter
ATX1000—2J29100	Overall dimensions of vehicle (mm)	3997*1470*1891
	dimensions of the cargo (mm)	1680*1150*850
	engine	1100
	engine rated power(kw)	12.1
	engine house power(hp)	17
	engine displancement	0.903
	rear axle	3+1 semi-float
	front tire	5.00-14
	rear tire	6.00-16
	brake mode	semi-float hydraulic brake
	wheel base (mm)	1140
	tread(mm)	2912
	plate spring	13
	weight of body	1500
	rated capacity	1500
	max speed	50





Model	Specification	parameter
ATX1500-3J40102	Overall dimensions of vehicle (mm)	4760*1480*1950
	dimensions of the cargo (mm)	2450*1460*950
	engine	1115
	engine rated power(kw)	16.2
	engine house power(hp)	22
	engine displancement	1.194
	rear axle	5+1gear full float
	front tire	6.00-14
	rear tire	7.00-16
	brake mode	full float hydraulic brake
	wheel base (mm)	1240
	tread(mm)	3360
	plate spring	13
	weight of body	1800
	rated capacity	2500
	max speed	50





Model	Specification	parameter
3P51400	loading capacity	3tons
	Overall dimensions of vehicle (mm)	5085×1580×2057
	dimensions of   tank (mm)	2900×1580×800
	wheel base (mm)	3392
	wheel track   (back) (mm)	1370
	steel spring number)	9+7
	suspention	triple suspention
	curb weight( kg)	1580
	max speed	49km/h
	engine	Quanchai 480
	tire size (F/R)	6.00-16
		7.50-16 with spare tire
	brake system	hydraulic brake
	gear box	520, 3*2+2
	bady	five star yuxiang B
	cab	one and a half row
	clutch	dry single, screw and spring
		255clutch
	rear axle	520,130 stamping rear axle ,speed rato5.833
	start mode	elctric start
	steering systum	worm and gear /18.2:1
	battery	single, 100Ah
	Qty in 40(units)	4units
	color	blue
