US$ 2,000 - 5,000
MOQ: 15 Units
Key Specifications
Get Latest Price
Use For:
Cargo
Driving Type:
Motorized
Displacement:
> 250cc
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Use For
Cargo
Driving Type
Motorized
Body Type
Open
Certification
Other, CE, ISO9001
Brand Name
BOTA ,FIVER STAR
Place of Origin
Shandong, China
Model Number
2B22104
Size
3720*1400*1720mm
three wheel motorcycle
Main Features
Adopt 160 stamping channel steel, the leaf spring externally spans the chassis, and the auto beam is manufactured by steel for better load capacity and a more stable and safer drive; with the guarantee that the chassis is the most reliable one among like products, which lowers the frame damage rate largely. Adopt stamping integrative lumber-core container, which adopts cathode electrophoresis coating with good processing, no rust and more reliable performance. The platform development of vehicle models has strong seriation and popularity and guarantees the stable quality and quick service. Enlarge the automobile steel welding fore vertical beam with butt welding of the channel steel which promotes stronger bearing capacity and stability and can bear additional impact of 2 tons or more compared with other products. The whole vehicle is sprayed by cathode electrophoresis painting technology in order to be more reliable and make sure there’s no rust due to metallic paint, which promotes the vehicle to be more valuable. The vehicle has a horizontal type large oil tank and long life mileage and installed a 1.7-meter wide container. The whole vehicle with reasonable and compact match has stronger practicability. The ATX vehicle body adopts GOA core technology and widen Pillar B of the vehicle door in order to be safer.
SPECIFICATION
| Model | Specification | Parameter |
| 2B22104 | loading capacity | 1.5tons |
| Overall dimensions of vehicle (mm) | 3720*1400*1720 | |
| dimensions of the cargo (mm) | 2200*1400*700 | |
| wheel base (mm) | 1180 | |
| wheel track (back) (mm) | 1220 | |
| steel spring number) | 13(7+6) | |
| width of cabin(mm) | 1100 | |
| rated power (Hp) | 13.2 | |
| Displacement ( L) | 0.996 | |
| curb weight( kg) | 930 | |
| max speed | 50 | |
| engine | 1105 | |
| tire size (F/R) | Front:4.50-14 | |
| Rear :6.00-16 | ||
| brake system | hydraulic system | |
| gear box | 3+1 | |
| brake system | foot brake; hand brake | |
| rear axle | 3+1 | |
| dump equipment | Yes | |
| Qty in 40hq (units) | SKD ,15units | |
| color | red |
| Model | Specification | parameter |
| ATX1000—2J29100 | Overall dimensions of vehicle (mm) | 3997*1470*1891 |
| dimensions of the cargo (mm) | 1680*1150*850 | |
| engine | 1100 | |
| engine rated power(kw) | 12.1 | |
| engine house power(hp) | 17 | |
| engine displancement | 0.903 | |
| rear axle | 3+1 semi-float | |
| front tire | 5.00-14 | |
| rear tire | 6.00-16 | |
| brake mode | semi-float hydraulic brake | |
| wheel base (mm) | 1140 | |
| tread(mm) | 2912 | |
| plate spring | 13 | |
| weight of body | 1500 | |
| rated capacity | 1500 | |
| max speed | 50 |
| Model | Specification | parameter |
| ATX1500-3J40102 | Overall dimensions of vehicle (mm) | 4760*1480*1950 |
| dimensions of the cargo (mm) | 2450*1460*950 | |
| engine | 1115 | |
| engine rated power(kw) | 16.2 | |
| engine house power(hp) | 22 | |
| engine displancement | 1.194 | |
| rear axle | 5+1gear full float | |
| front tire | 6.00-14 | |
| rear tire | 7.00-16 | |
| brake mode | full float hydraulic brake | |
| wheel base (mm) | 1240 | |
| tread(mm) | 3360 | |
| plate spring | 13 | |
| weight of body | 1800 | |
| rated capacity | 2500 | |
| max speed | 50 |
| Model | Specification | parameter |
| 3P51400 | loading capacity | 3tons |
| Overall dimensions of vehicle (mm) | 5085×1580×2057 | |
| dimensions of tank (mm) | 2900×1580×800 | |
| wheel base (mm) | 3392 | |
| wheel track (back) (mm) | 1370 | |
| steel spring number) | 9+7 | |
| suspention | triple suspention | |
| curb weight( kg) | 1580 | |
| max speed | 49km/h | |
| engine | Quanchai 480 | |
| tire size (F/R) | 6.00-16 | |
| 7.50-16 with spare tire | ||
| brake system | hydraulic brake | |
| gear box | 520, 3*2+2 | |
| bady | five star yuxiang B | |
| cab | one and a half row | |
| clutch | dry single, screw and spring | |
| 255clutch | ||
| rear axle | 520,130 stamping rear axle ,speed rato5.833 | |
| start mode | elctric start | |
| steering systum | worm and gear /18.2:1 | |
| battery | single, 100Ah | |
| Qty in 40(units) | 4units | |
| color | blue |
