Home > Products > Wheel Loader > AS966 Construction Machines 966H Heavy Wheel Loader Black and White
AS966 Construction Machines 966H Heavy Wheel Loader Black and White
US$ 51,000 - 55,000
/ Set
1 Set(Min. Order)
- Qingdao Port China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Ethiopia Hot Model Wheel Loader 966H With 3.5m3 Bucket and ZF 4WG180 Transmission
-
AS966 Construction Machines 966G Heavy Wheel Loader Black and White
-
AS966H Construction Machines 966G Heavy Wheel Loader Black and White
-
ZL50G Wheel Loader Bucket Capacity 2.7-4.5m3 160KWengine 23.5-25tire
-
ZL50G Wheel Loader
-
ZL40F Wheel Loader
Product Details
| Condition | New | Brand Name | ANSION | |
| Model Number | 966H | Place of Origin | Shandong, China | |
| Type | Front Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | 8250 x 3100 x 3400 mm | Rated Load | 6000 kg | |
| Certification | ISO9001 | Warranty | 12 months | |
| After-sales Service Provided | No overseas service provided |
Product Description
wheel loader 966H with 3.5m3 bucket and ZF 4WG200 transmission and CAT C6121 engine
| Wheel Loader Model | 966H | ||
| Operating weight(kg) | 19800 | ||
| Rated bucket capacity(m3) | 3.5 | ||
| Rated load(kg) | 6000 | ||
| Tractive force(Kn) | 158 | ||
| Breakout force (Kn) | 204 | ||
| Travel speed(km/h) | 0-38 | ||
| Min. turning radius(mm) | 7020 | ||
| Max. Dumping height(mm) | 3450 | ||
| Max. Dumping distance(mm) | 1250 | ||
| Wheel base(mm) | 3200 | ||
| Engine brand | WEICHAI / SHANGCHAI (Caterpillar) / CUMMINS | ||
| Engine type | Diesel, 4 stroke, water cooled | ||
| Rated power(KW) | 175 (=240HP) | ||
| Transmission | ZF 4WG200 electric control | ||
| Gear shift | 4+3 | ||
| Hydraulic system pressure (MPa) | 18 | ||
| Bucket lift time (s) | 5.95 | ||
| Total cycle time (s) | 10.95 | ||
| Fuel tank volume (L) | 300 | ||
| Bucket auto level funtion | Yes | ||
| Service brake | Hydraulic over oil disc | ||
| Parking brake | Manual | ||
| Tyres | 26.5-25 | ||
| Total dimension (L x W x H)/mm | 8250 x 3050 x 3400 | ||
