ZLJ20F Mini Mining Front Loader With 0.9m3 Bucket and 78HP Engine

rated loading

2000kg

overall weight

4600kg

rated bucket capacity

0.9m3

maximum tractive force

≥38.2KN

maximum breakout force

≥48.8KN

maximum grade ability

30 o

maximum dump height

1300mm

maximum dump reach

952mm

overall dimension (L×W×H)

4850x2000x1330mm (without canopy)

minimum turning radius

4743mm

model

4102GB

type

Vertical, in-line, water cooled, 4-stroke diesel engine

No. of cylinder-bore/stroke

4—102×115mm

rated power

58kw—2400r/min

maximum torque

265N.m---1600R--1800nin

min fuel-consume ratio

≤238g/kw.h

torque converter

YJ—265A

gearbox mode

Countershaft power-shift

gear shift

2 forward shift  2 reverse shift

maximum speed

24km/h

main reducing mode

Circular Arc Bevel gear, single stage

decelerating mode

Single stage planetary type

wheel base (mm)

2350mm

wheel tread

1450mm

ground clearance

170mm

system working pressure

16MPa

boom lifting time

4.8s±0.2s

total time

9.2s±0.5s

fuel tank capacity

80L

function of leveling automatically

yes

service brake

air assist disc brake on 4 wheels

parking brake

flexible shaft operated external drum

type specification

12-16.5

front tyre pressure

0.22Mpa

rear tyre pressure

0.18Mpa
