Specifications
High efficiency, flexible, reliable, easy maintenance, energy saving.1.Brief introduction of Jaw crusher:
PE series of Jaw crusher is a kind of rough crushing device which is widely used both at home and abroad at present. It is mainly used in primary and rough crushing of all kinds of hard rocks and large block material. Large and medium-sized jaw crushers are the main products of our company and have taken the leading position in the world.
2. Application
ZG-PE type jaw crusher industry has become extremely sophisticated crusher is widely used in mining, smelting, building material, highway, water conservancy and chemical industry and other industries, with a crushing ratio, even granularity, simple structure, reliable, easy maintenance, operating costs and economic characteristics. Be not more than 320 MPa breaking strength of various materials, is the first primary crushing equipment.
3.Working principle of Jaw crusher:
Firstly the machine’s leather belt and wheel are driven by the electric motor, then the movable jaw plate begins to move up and down by the eccentric shaft, when the movable jaw plate moves from top to bottom, the angle between fixed jaw plate and movable jaw plate becomes smaller, the material is crushed into pieces to reach the crushing target. When the movable jaw plate moves from bottom to top, the angle between fixed jaw plate and movable jaw plate becomes bigger, the movable jaw plate deviates from the fixed jaw plate under the function of drag rod and spring, at this moment, the crushed material is discharged from the bottom outlet of the crushing cavity.
4.Specifications of Jaw crusher:
Model |
Feeding opening size(mm) |
Max.Feeding granularity(mm) |
Discharge opening adjustment range(mm) |
Capacity(m³/h) |
Weight(kg) |
Motor Power(kw) |
PE-250*400 |
250*400 |
210 |
20-60 |
3-13 |
2800 |
15 |
PE-400*600 |
400*600 |
340 |
40-100 |
10-35 |
6500 |
30 |
PE-500*750 |
500*750 |
425 |
50-100 |
25-60 |
10300 |
55 |
PE-600*900 |
600*900 |
500 |
65-180 |
30-85 |
15500 |
55-75 |
PE-750*1060 |
750*1060 |
630 |
80-180 |
72-150 |
28000 |
110 |
PE-900*1200 |
900*1200 |
780 |
95-180 |
90-190 |
50000 |
132 |
PE-1200*1500 |
1200*1500 |
1020 |
150-300 |
250-500 |
100900 |
160 |
PEX-150*750 |
150*750 |
210 |
18-48 |
5-16 |
3500 |
15 |
PEX-250*750 |
250*750 |
210 |
25-60 |
8-22 |
4900 |
22 |
PEX-250*1000 |
250*1000 |
210 |
25-60 |
10-32 |
6500 |
30-37 |
PEX-250*1200 |
250*1200 |
210 |
26-60 |
13-38 |
7700 |
37 |
PEX-300*1300 |
300*1300 |
250 |
20-90 |
10-65 |
11000 |
75 |
5.Company info:
Zibo XinWan Group is dedicated to all kinds of construction machinery and equipment companies. The main production and operation of submersible pumps, vacuum pumps, sand production line, reduction gearboxes.
With 15 years of reducers production, powerful technical force, and complete inspection measures, quality Management System is in conformity with GB/T19001-2000-ISO9001:2000 standard.
