1/3 Sony Effio V CCD Hi-Re 800TV Line Mini FPV OSD Camera

1/3 Sony Effio V CCD Hi-Re 800TV Line Mini FPV OSD Camera photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Correa
Model Number:
CSY3130EV
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Correa
Model Number CSY3130EV
Type Analog Camera
Style Mini Camera
Sensor CCD
Technology Other, Board Lens
Special Features Other, with OSD function

Specifications

1/3 Sony Effio V CCD Hi-Re 800TV Line Mini FPV OSD Camera
1. Tiny: 30x30mm
2. DC12V
3. With OSD Function



1/3 Sony Effio V CCD Hi-Re 800TV Line Mini FPV OSD Camera

    The newest FPV camera with Effio-v tech. and 800tvl high resolution. Suitable for ATM surveillance and Aerial Photography, FPV(first person view play) etc.



Description:

> 1/3" SONY double-scan CCD
SONY Effio-V,CXD4141GG
800TVL Resolution
> 0.01Lux / F2.0
> AGC,Shutter,Privacy,Motion,HLC/BLC
> Day&Night
> WDR,ATR-EX2,
> E-Zoom,DIS ,3D-DNR
> Built in OSD
> Size:30x30mm



Spec.:

Model No.

CSY3130EV

Image Device

1/3" SONY double-scan CCD

Scanning System

2:1 Interlace

Scanning Frequency

PAL : 15.625 KHz(H), 50Hz(V) / NTSC : 15.734 KHz(H), 59.94 Hz(V)

H. Resolution

800TVL

Effective Pixels

PAL: 976 (H) X 582(V) / NTSC: 976 (H) X 494 (V)

S/N Ratio

More than 52dB(AGC 0FF)

Min. Illumination

0.01 Lux  / F2.0

Shutter

Auto,Manual,Fix

AGC

6DB~44.8DB

White Balance

ATW, PUSH/PUSH LOCK, USER1/USER2, MANUAL

WDR,ATR-EX

Normal/Light

DNR

3D-DNR

Day&night

Color, Auto, B/W

Privacy

Off, On(15 area)

Motion Detection

Off, On(4 area)

E-Zoom,DIS

Off / On(0~255)

HLC/BLC

OFF/ BLC/ HLC

Language

English, French,Russian, Spanish, Dutch,Chinese, Japan, Portuguese

Lens

3.6mm board lens(optional)

Power Comsumption

DC12V

Dimensions (mm)

30x30mm





1/3 Sony Effio V CCD Hi-Re 800TV Line Mini FPV OSD Camera



1/3 Sony Effio V CCD Hi-Re 800TV Line Mini FPV OSD Camera
