Sony 20x20mm 420TVL Very Small Hidden Surveillance Camera

Sony 20x20mm 420TVL Very Small Hidden Surveillance Camera photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Correa
Model Number:
CS3120CDN
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Correa
Model Number CS3120CDN
Type Other, Digital Camera, Video Camera
Style Mini Camera
Sensor CCD
Technology Other, Lens optional
Special Features Other, Small size and lightweight

Specifications

420TVL Very Small Hidden Surveillance Camera
1. Low current consumption
2. Impressive Quality
3. 20x20mm



Sony 20x20mm 420TVL Very Small Hidden Surveillance Camera

Description:

    This Correa made Micro FPV Camera offers impressive performance and high quality images! Utilizied by 1/3" SONY Color CCD, this camera offers best-in-class white pixel handling technology along with improved color balance and image clarity. The 1/3" SONY CCD provides one of the most vivid FPV flying experiences.





Specifications:
Image Device:1/3" Sony SuperHAD II Color CCD
Horizontal Resolution:420 TV Line
Minimum Illumination:0.5 lux (day) 0.05 (night)
Number of Pixels: PAL: (H)500x(V)582; NTSC: (H)510x(V)492
Scanning System PAL: 625 Lines, 50 Field/Sec; NTSC: 525 Lines, 60 Field/Sec
Sync System:Internal Synchronization
Video output:1Vp-p 75 Oms , Negative
White Balance:Auto
S/N Ratio:More Than 48dB (AGC off)
Gamma Characteristic:0.45
Electronic Shutter:PAL : 1/50~1/100,000 Sec; NTSC : 1/60~1/100,000 Sec, auto
Lens:3.6mm MTV lens
Power Consumption:DC 5-15V, 50mA-150mA
Housing:Black
Dimension:20x20mm, 2-board
Weight:24g



Suitable for Aerial Video, ATM surveillance and other CCTV security system. (Pinhole Lens, Wide angle lens optional)



 Details:

Image Device
1/3" Sony Super HAD II Color CCD
Horizontal Resolution
420 TV Line
Minimum Illumination
0.5 lux (day) 0.05 (night)
Number of Pixels
PAL: (H)500x(V)582; NTSC: (H)510x(V)492
Scanning System
PAL: 625 Lines, 50 Field/Sec; NTSC: 525 Lines, 60 Field/Sec
Sync System
Internal Synchronization
Video output
1Vp-p 75 Oms , Negative
White Balance
Auto
S/N Ratio
More Than 48dB (AGC off)
Gamma Characteristic
0.45
Electronic Shutter
PAL : 1/50~1/100,000 Sec; NTSC : 1/60~1/100,000 Sec, auto
Lens
3.6mm MTV lens
Power Consumption
DC 5-15V50mA
Housing
Black
Dimension
20x20mm, 2-board
