5.8 Ghz Long Range FPV Antenna 12dBi Helical w/ Fiber-glass Cover High Gain
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CORREA
Model Number:
ANT-HA12H
Payment & Shipping
Payment Methods:
Port of Shipment:
HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mini Drones Sony 600TVL Board Camera FPV SystemNegotiableMOQ: 1 Piece -
FPV Camera Cable With 3 Pin Servo PlugNegotiableMOQ: 100 Pieces
-
95mm Aluminum Alloy Gauge Meters Wheel (Inner Hole Diameter of 8 Mm)14004US$ 10 - 10MOQ: 1 Piece
-
95mm Aluminum Alloy Gauge Meters Wheel(Inner Hole Diameter 6 Mm) 14003US$ 10 - 10MOQ: 1 Piece
-
6mm 3 Piece Black Anodized Coupling Sets 18005US$ 18 - 18MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
CORREA
Model Number
ANT-HA12H
High Quality 5.8 GHz Helical Aerial RHCP 5.8G FPV Antenna
ELECTRICAL SPECIFICATIONS:
Frequency Range: 5725~5875 MHz
Impedance: 50Ω
VSWR : < 1.5
Gain: 12 dBi
Polarization: RHCP
Horizontal 3dB Beam Width: 38°
Vertical 3dB Beam Width: 38°
Front to Back Ratio: 15 dB
Maximum Input Power 50 W
Connector: SMA Female
Lighting Protection: Direct Ground
MECHANICAL SPECIFICATIONS:
Size: Ø35×112 mm
Weight: 48 g
Color: White
Material of the Case: PVC
Radiating Element Material: Radome Material
Reflector Material: Aluminum Alloy
