| The parameter and style of High Durable Wire thread inserts | |||||||
| METRIC PARAMETER | |||||||
| d | p | xd | l | w | Dz | do | |
| 2 | 0.4 | 1d | 2 | 2.9 | min | max | 2.1 |
| 1.5d | 3 | 4.9 | 2.6 | 2.8 | |||
| 2d | 4 | 6.9 | |||||
| 2.5d | 5 | 8.9 | |||||
| 3d | 6 | 10.9 | |||||
| 2.5 | 0.45 | 1d | 2.5 | 3.5 | 3.3 | 3.5 | 2.6 |
| 1.5d | 3.75 | 5.9 | |||||
| 2d | 5 | 8.1 | |||||
| 2.5d | 6.25 | 10.5 | |||||
| 3d | 7.5 | 12.9 | |||||
| 3 | 0.5 | 1d | 3 | 3.9 | 3.8 | 4 | 3.1 |
| 1.5d | 4.5 | 6.3 | |||||
| 2d | 6 | 8.7 | |||||
| 2.5d | 7.5 | 11.1 | |||||
| 3d | 9 | 13.5 | |||||
| 3.5 | 0.6 | 1d | 3.5 | 3.7 | 4.42 | 4.6 | 3.7 |
| 1.5d | 5.25 | 6.3 | |||||
| 2d | 7 | 8.7 | |||||
| 2.5d | 8.75 | 11.2 | |||||
| 3d | 10.5 | 13.3 | |||||
| 4 | 0.7 | 1d | 4 | 3.7 | 5.05 | 5.25 | 4.2 |
| 1.5d | 6 | 6.1 | |||||
| 2d | 8 | 8.4 | |||||
| 2.5d | 10 | 10.9 | |||||
| 3d | 12 | 13.2 | |||||
| 5 | 0.8 | 1d | 5 | 4.3 | 6.35 | 6.6 | 5.2 |
| 1.5d | 7.5 | 6.9 | |||||
| 2d | 10 | 9.7 | |||||
| 2.5d | 12.5 | 12.3 | |||||
| 3d | 15 | 14.8 | |||||
| 6 | 1 | 1d | 6 | 4.2 | 7.6 | 7.85 | 6.3 |
| 1.5d | 9 | 6.9 | |||||
| 2d | 12 | 9.6 | |||||
| 2.5d | 15 | 12.3 | |||||
| 3d | 18 | 14.6 | |||||
| 7 | 1 | 1d | 7 | 5.3 | 8.65 | 8.9 | 7.3 |
| 1.5d | 10.5 | 8.2 | |||||
| 2d | 14 | 11.1 | |||||
| 2.5d | 17.5 | 14.3 | |||||
| 3d | 21 | 17.4 | |||||
| 8 | 1.25 | 1d | 8 | 4.7 | 9.85 | 10.1 | 8.3 |
| 1.5d | 12 | 7.4 | |||||
| 2d | 16 | 10.6 | |||||
| 2.5d | 20 | 13.5 | |||||
| 3d | 24 | 16.4 | |||||
| Because the space is limited , We Only listed a few specifications of wire thread inserts . if you want to learn more,Welcome to contact me any time | |||||||
The specifications of High Durable Wire thread inserts
Having more than 50 years of experiences in this field, and with background of military technology.
1.Increase the bearing capacity of the threaded connection and fatigue strength
2.Good.abrasion Resistance
3.Corrosion resistance
4.High precision
5.High temperature resistance
New type of High Durable Wire thread inserts.
1.drilling 2.tapping 3.put thread in wrench 4.installing
5.breaking 6.finished 7.putting bolt in
Xinxiang Bashan Aero Material Co., Ltd.
In more than 60 years experience of metal wire cold drawing, metal wire mesh weaving and deep processing products, Bashan company acquired 24 metal wire & mesh patents and took chief part of 19 standards, such as GB/T4240, GB/T5330, GB/T6003, GJB107, HB1862, etc. (GB/T, national standard; GJB national military defense standard; HB, aviation standard.)
1）Passed ISO9001:2008 quality certificate
2）Passed ISO/TS16949:2009 certificate
3）Passed GJB9001A-2001 military quality certificate.
4）Drafted GJB119.1A-119.4A-2001, GJB107-5110-2002, GB/T5330-2003,HB1862-93
ISO3310 200mm perforated metal plate Test sieves 1mm to 32mm.
Packing Details
* Inner: Plastic bag
Out: Carton or wooden case or according to the weight
* Pallet / Wooden Crate.
* Customized packing.
Processing & Delivery Time
* Common products in 2-4 days.
* Special products according to Contract.
* Small package is shipped by Air, DHL, FedEx etc.
4-10days.
* Big size package is shipped by sea, 10-30days.
MOQ
* 500 Piece/Pieces
* If no Stock, please contact the supplier to confirm it.
* Payment terms: L/C,T/T,Western Union
* Trade term: EXW/ FOB/ CIF.
ISO3310 200mm perforated metal plate Test sieves 1mm to 32mm.
Delivery and payment and after-sale service
