Help CenterGZD/ZSW Linear Vibrating Feeder ZSW-600x300
Related Products
-
Iron Stone Crushing Plant Vibrating FeederUS$ 1,000 - 500,000MOQ: 1 Set -
XSD Sand Maker AND Sand Production Line ---CHINA YUFENGNegotiableMOQ: 1 Set
-
Sand Making Machine, Also Known as Vertical Shaft Impact Crusher--CHINA YUFENGNegotiableMOQ: 1 Set
-
Sand Making Machine, Also Known as Vertical Shaft Impact Crusher--CHINA YUFENGNegotiableMOQ: 1 Set
-
Stone Sand Making Machine Line--CHINA YUFENGNegotiableMOQ: 1 Set
magnetic vibrating feeder Descriptions
Feeding Machine, Vibrating Feeder is used to feed block or granule materials from material storage to a charging device evenly and continuously. Used to achieve an even feeding for crushers in sandstone production lines, and to make a rough screening of materials, this equipment is widely used in combined operation with crushing and screening machines in a range of industries
magnetic vibrating feeder, Vibrating Feeder Features
1) Stable vibrating feeding volume
2) Reliable operation, long usage life
3) Adjustable excitation force and
4) Stable and convenient control of flow
5) Vibrating motor as excitation source
a) Low noise
b) Low power consumption
6) Good adjusting performance and without material splash
7) Simple structure
8) Convenient to install and maintain
9) Light weight, small size
10) Enclosed type can prevent dust pollution (optional)
magnetic vibrating feeder Operating principle
Vibrating feeder consists of vibrating frame, spring, vibrator, motor vibrating device and motor. The vibrator is made of two fixed eccentric shafts whose gears are jogged. When installation, the two gears must be jogged according to the sign. Through drive of the motor, the two eccentric shafts start rotating to produce a linear huge power which forces the feeder to vibrate. Through the vibration, The materials will slip and sling on the funnel, moving forward, when the materials pass the screening part, smaller parts will fall down, avoiding the further crushing, so screening purpose can be reached
magnetic vibrating feeder main technical parameters:
Model |
Funnel size (mm) |
Max Feed size(mm) |
Capacity (t/h) |
Power(kw) |
Weight(T) |
Dimensin(LxWxH) |
GZD-850X3000 |
850X3000 |
400 |
80-120 |
7.5 |
3895 |
3110X1800 |
GZD-960X3800 |
960X3800 |
500 |
120-210 |
11 |
3980 |
3850X1950 |
GZD-1100X4200 |
1100X4200 |
580 |
200-430 |
15 |
4170 |
4400X2050 |
GZD-1100X4900 |
1100X4900 |
580 |
280-500 |
15 |
4520 |
5200X2050 |
GZD-1300X4900 |
1300X4900 |
650 |
450-600 |
22 |
5200 |
5200X2350 |
....
