Help CenterHigh Effiency 5LL Chromite Spiral Chute
Related Products
Specifications
Spiral Chute1. used in mining industry
2.for concentrating
3direct manufacturer
Spiral Chute which combines the advantages of spiral concentrator, shaking table and centrifugal concentrator, is a new beneficiation equipment with the advanced level.
It is applicable for separation of granularity ranged from 4mm to 0.02mm metallic minerals such as iron, ilmenite, chromite, tungsten-tin ore, niobium- tantalum ore, gold placer, seashore monazite, rutile and zircon as well as other metallic and non-metallic minerals with adequate difference of specific gravity.
This equipment applies to size 0.3-0.02mm thin materials of iron, ilmenite, chromite, zircon, rutile, monazite, P B ore, tungsten ore, tin mine, tantalum mine, as well as other non-ferrous metals, precious metals and non-metallic mineral with the proportion differences. The equipment is stable, easy to control, to allow changes in the thickness, small footprint, less water consumption, simple structure, no driving fore, big capacity, simple to istall, convenient operation, small investment and so on advantages.
According to the different proportions, granularities, shapes of the mineral sand, mineral sand will be divided by the effect of gravity and centrifugal force
| Model | Outer diameter(mm) | Inner diameter(mm) | Screw pitch(mm) | Span ratio | Inclination angle (o) | Number of thread | Number of circle | Feeding granularity (mm) | Feeding concentration (%) | Production capability (L/h -1 ) | Floor area (m 2 ) | Height (m) |
| D12000 | 2000 | 2000 | 1200 | 0.6 | 9 | 2-4 | 3.5 | 0.04-4 | 20-40 | 15-45 | 5-7 | 6.8 |
| D11500 | 1500 | 150 | 900 | 0.6 | 9 | 2-4 | 4 | 0.03-0.3 | 20-45 | 10-25 | 5-8 | 6.1 |
| D11200 | 1200 | 1200 | 720 540 | 0.6 | 9 | 2-4 | 4-5 | 0.03-0.3 | 30-50 | 4-6 | 2 | 5.23 |
| L1900 | 900 | 900 | 540 360 | 0.4 0.6 | 9 | 2-3 | 4-5 | 0.03-0.3 | 30-50 | 2-3 | 1,2 | 4 |
| L1600 | 600 | 600 | 390 360 | 0.4 | 9 | 1-2 | 4-5 | 0.02-0.2 | 30-50 | 0.8-12 | 0.5 | 2.6 |
| L1400 | 400 | 400 | 180 | 0.45 | 9 | 1-2 | 4-5 | 0.02-0.2 | 30-50 | 0.5-0.2 | 0.25 | 1.3 |
