Help CenterHigh Efficiency Coal Gas Producer
Related Products
Specifications
improve coal heat efficiency,reduce low consumption 20-40%coal gasifier environmentally
automatic
Coal Gasifier Introductions
This series of coal gasifier, developing from and taking good advantages of dry-type ash-cleaning gas furnace, is a new genration of intelligent high efficient environment-friendly products manufactured by our company, in which patened rotating disk slag cleaning and automatical slag cleaning structure are used.
Coal Gasifier Characteristics
♥ Using pagoda-shaped heat-resistant iron grate;
♥ The furnace wall is always protected by slags, strong effect of slag breaking, slag loosing and ventilation;
♥ Our coal gasifier elimates the concept that gas furnace is the same as pressure vessel;
♥ Our coal gasifier achieve the auto control of the temperature;
Continual coal gasifier uses national invention patented technology, eliminating the hidden trouble of traditional coal gasifier's easy explosion.
Our company designs the manufacturer producer gas generator, is take the air and the steam as vaporization medicinalpreparation, production combination gas advanced equipment, this equipments suits the vaporization coking coal, fuel and so on Jiao Tan, widely applies in machine, metallurgy, chemical industry, glass, building materials, light industry, food, textile industry heating dry kiln.
coal gas producer features
1) the producer gas generator may enhance the thermal efficiency, also the coal burning if full, many reduce the energy to disappear, with direct coal-burning, may reduce disappears 20-40 otranslation.
2) The gas generator may cause the necessary kiln stove temperature big 1500°, moreover, in kilin temperature difference.
3) The producer gas generator conforms to the industry kiln gas to discharge the GB9079.88 waste residue the platoon, uses the wet dregs, does not have the dirt has certain social efficieny.
4) The use producer gas generator may imporve the worker to work obviously the environment, reducers the labor intensity, since therefore being published deeply user’s welcome.
Coal Gasifier Specifications:
| Model(mm) | QM0.8 | QM1.0 | QM1.2 | QM1.5 | QM1.6 | QM1.8 | QM2.0 | QM2.4 | QM2.6 | QM3.0 | QM3.2 |
| Chamber diameter(mm) | 800 | 1000 | 1200 | 1500 | 1600 | 1800 | 2000 | 2400 | 2600 | 3000 | 3200 |
| Hearth active surface | 0.5 | 0.785 | 1.13 | 1.77 | 2.01 | 2.54 | 3.14 | 4.52 | 5.31 | 7.07 | 8.04 |
| Suirable fuel | weak coherent gas carbon,anotherracite,burnt carbon | ||||||||||
| Fuel granularity(mm) | 25-80 | ||||||||||
| Fuel consumption quantitykg/h | 40-100 | 70-140 | 120-190 | 160-350 | 350-460 | 500-600 | 500-720 | 700-1040 | 850-1200 | 1700-2000 | 1800-2200 |
| Gasifying agent | Air ,steam | ||||||||||
| Gas yieldNm³/h) | 140-350 | 245-490 | 420-670 | 560-1200 | 1200-1600 | 1500-2100 | 1750-2500 | 2500-3600 | 3000-4300 | 6000-7000 | 6500-7500 |
| Gas calorific valu(Kj/Nm³ | 5020-5670 | 5020-6000 | |||||||||
| Water jacket heating area(m2) | 4.02 | 5.02 | 6.78 | 10.37 | 11.06 | 12.44 | 17.58 | 21.87 | 23.69 | 30.16 | 32 |
| Steam output kg/h | 60 | 80 | 130 | 200 | 220 | 260 | 350 | 420 | 600 | 840 | 200 |
| Gas outlet temperature(°C) | (400-500)Plants related with the coal | (400-500)Plants related with the coal | |||||||||
| Gas outlet pressure(Pa) | 1000 | 980-1470 | 1470-1960 | 980-1470 | |||||||
| Gas exportation diameter(mm) | 219 | 325 | 325 | 426 | 426 | 529 | 630 | 720 | 820 | 1020 | 900 |
| Air pressure(Pa) | 3000 | 4000 | 3000 | ||||||||
| Saturated air temperature(°C) | 50-60 | 50-65 | |||||||||
| Ashpan rotational speed(r/h) | 0.177-1.77 | ||||||||||
| Equipment gross weight(t) | 3.5 | 4.5 | 5 | 7.5 | 10 | 20 | 23.4 | 29.8 | 32 | 37.6 | 16 |
| Complete machine power(kw) | 6 | 6 | 6 | 7 | 8 | 10 | 14 | 20 | 20 | 27 | 7 |
| Tuyere diameter(mm) | 108 | 108 | 140 | 165 | 219 | 325 | 325 | 426 | 426 | 426 | 219 |
