Indirect heat transfer rotary crushed stone dryer machine

Specifications

crushed stone dryer machine
1.used in building materials,metallurgy, chemical industry
2.energy-saving
3. high productivity

 Indirect heat transfer rotary crushed stone dryer machine
1.used in building materials,metallurgy, chemical industry
2.energy-saving
3. high productivity



 Indirect heat transfer  rotary dryer machine



The indirect heat transfer dryer made by our company is mainly used in building materials . metallurgy, chemical industry, cement plant for drying of limestone slag, coal power , slag, clay stone . This dryer is formed by rotary body, lifting blade, driving device, supporting device and sealing ring. The dryer has advantages of reasonable structure, high efficiency, low energy consumption and convenient for transportation.



Technical parameters of indirect heat transfer  rotary dryer machine :



Item   Shell diameter*shell length	Inside diameter of outer shell(mm)	Inside diameter of inner shell(mm)	Shell length (mm)	Shell cubage (m3)	Shell obliquity	Lifting blade form	Highest inlet air temperature ()	Dimension (m)
φ1.5*15m φ1.5*17m φ1.5*19m	1500	500	15 17 19	20.27 22.97 25.68	3-5%	Lifting form	850	16.2*2.7*2.7 18.2*2.7*2.7 20.0*2.9*2.9
φ1.8*21m φ1.8*23m φ1.8*25m	1800	600	21 23 25	35.91 39.33 42.75	3-5%	Lifting form	850	22.5*2.7*2.7 24.5*2.9*2.9 26.5*2.9*2.9
φ2.2*21m φ2.2*23m φ2.2*25m	2200	800	21 23 25	58.10 63.61 69.15	3-5%	Lifting form	850	-----------------
