Specifications
dryer machine1.used in building materials,metallurgy, chemical industry
2.Lower power consumption
3. high productivity
Indirect heat transfer rotary dryer machine
The indirect heat transfer dryer made by our company is mainly used in building materials . metallurgy, chemical industry, cement plant for drying of limestone slag, coal power , slag, clay stone . This dryer is formed by rotary body, lifting blade, driving device, supporting device and sealing ring. The dryer has advantages of reasonable structure, high efficiency, low energy consumption and convenient for transportation.
Technical parameters of indirect heat transfer rotary dryer machine :
|
Item
Shell diameter*shell length |
Inside diameter of outer shell(mm) |
Inside diameter of inner shell(mm) |
Shell length (mm) |
Shell cubage (m3) |
Shell obliquity |
Lifting blade form |
Highest inlet air temperature () |
Dimension (m) |
|
φ1.5*15m φ1.5*17m φ1.5*19m |
1500 |
500 |
15 17 19 |
20.27 22.97 25.68 |
3-5% |
Lifting form |
850 |
16.2*2.7*2.7 18.2*2.7*2.7 20.0*2.9*2.9 |
|
φ1.8*21m φ1.8*23m φ1.8*25m |
1800 |
600 |
21 23 25 |
35.91 39.33 42.75 |
3-5% |
Lifting form |
850 |
22.5*2.7*2.7 24.5*2.9*2.9 26.5*2.9*2.9 |
|
φ2.2*21m φ2.2*23m φ2.2*25m |
2200 |
800 |
21 23 25 |
58.10 63.61 69.15 |
3-5% |
Lifting form |
850 |
----------------- |
