Specifications
10CBM concrete mixer truck1. self loading
2. long transport distance
3. volumetric truck
4. perfect after-sales service
10CBM concrete mixer truck for sale
Features
Capacity ranges from 6m3 to 16m3
Self-loading, self-mixing, self-supplying water, self-discharging
Constraction machinery/concrete mixer truck/concrete transportation truck
This type concrete mixer truck most widely used is the Cement Truck – Materials are loaded at a concrete mixing plant, Then the concrete is mixed in transit and delivered to job sites.
The concrete can be unloaded via a chute for ground level applications or the concrete is poured into a concrete pump system for high height applications.The capacity of concrete mixer truck ranges from 6 m³ to 16m³, meeting customers' various needs.
Main structure of the mixer machine
Classis; update, drive shaft hydraulic, reducer system; tanker; discharging; cleaning system; frame,; manual system; roller system; filling system; electric system.
Technical parameter of the mixer machine
Item |
|
7m³ concrete truck mixer |
8m³ concrete truck mixer |
9m³ concrete truck mixer |
10m³ concrete truck mixer |
12m³ concrete truck mixer |
||
Drum |
Geometric volume(m³) |
12.1 |
13.8 |
16.5 |
17.5 |
20.5 |
||
Effective agitate volume(m³) |
7 |
8 |
9 |
10 |
12 |
|||
Effective mixing volume(m³) |
5 |
6 |
7.5 |
8.5 |
10.5 |
|||
Inclination angle |
15 |
15 |
12 |
11 |
11 |
|||
Rotational velocity(r/min) |
0~14 |
|||||||
Rotation direction(from the rear of truck) |
Charge in clockwise, discharge in anticlockwise |
|||||||
Vane |
Double-screw vane |
|||||||
Discharge capacity |
When the slump is 5cm≥2m³/min |
|||||||
Remnant |
When the slump is 5cm≤1% |
|||||||
Charge and discharge device |
Hopper (L×W)(mm) |
950×1000 |
||||||
The main hopper length (mm) |
1600 |
|||||||
The annex hopper length(mm) |
780 |
|||||||
Water supply system |
Water pump (WP24-180B12)or(WP24-180B12) |
|||||||
Hydraulic system |
Oil pump |
A4VTG71 |
A4VTG71 |
A4VTG71 |
A4VTG90 |
A4VTG71/32R |
||
Motor |
Deutschland Rexthroth |
PLM7 |
PLM7 |
PLM9 |
PLM9 |
|||
AA2FM63 |
(3in1) |
(3in1) |
(3in1) |
(3in1) |
||||
chassis |
Type of engine/Power |
WD615.87/213
|
WD615.69/247 WD615.87/213 |
WD615.69/247 |
WD615.69/247 |
WD615.47/273 |
||
