8CBM capacity 6m3 to 16m3 concrete mixer truck

Specifications

Concrete mixer truck:
1,Self-loading
2,self-mixing
3,self-supplying water
4,self-discharging

               8CBM capacity 6 m³ to 16m³ concrete mixer truck



Introduction of concrete mixer truck:

This type concrete mixer truck most widely used is the Cement Truck – Materials are loaded at a

concrete mixing plant, Then the concrete is mixed in transit and delivered to job sites.

The concrete can be unloaded via a chute for ground level applications or the concrete is poured

into a concrete pump system for high height applications.The capacity of concrete mixer truck

ranges from 6 m³ to 16m³, meeting customers' various needs.

Main structure of concrete mixer truck:

Classis; update, drive shaft hydraulic, reducer system; tanker; discharging; cleaning system;

frame,; manual system; roller system; filling system; electric system.

Parameters of 12m³ concrete mixer truck:

8CBM capacity 6 m³ to 16m³ concrete mixer truck

Item	Unit	Parameter
Overall dimensions	mm	9655*2495*3950
GVW	kg	Appro×25000
Mass in working order		Appro×14750
Loading capacity		Appro×10055
Approach/departure angle	°	20/26
Exhaust/hp	ml/hp	11596/340
Max speed	km/h	90
Wheel base	mm	4100+1350
Axle load	kg	7500,16000
Tire specification	12:00R20	Engine type	WP10.340E
Traction system	6×4	Transmission	RTD11509C
Number of axles	3	Emission standard	Euro 3
Brake system instruction	Spring brake	Allowable passengers in cab	2
Effective mixing capacity	12000L
