Hammer crusher in the process of ball mill iron ore
This type hammer crusher is suitable for the crushing of medium hardness and brittle materials in mining, cement, coal, building material, road and chemical industry. The materials can be coal, coal gangue, salt, chalk, gypsum, bricks or tiles, limestone, feldspar and so on.
Working principle,
The main working parts is rotor with hammer head. Rotor consists of main shaft, disk, disc, axis pin and a hammer head. The motor drives the rotor to rotate with a high speed in the crushing cavity. From the upper materials are fed into the machine, and they are grinded and crushed by hit, impact, cut and grind of the high-speed hammer head. There is a sieve at the bottom of the rotor, the qualified final products are discharged from sieve, and others stay above the sieve, hit and grind, until their size is small enough to get through the sieve.
Features,
This hammer crusher has the features or small dimension, light weight, simply structure, easy operation and maintenance, high crushing ration, uniform final products, big capacity and so on. It’s better for the materials with brittle, medium hardness, compression strength 150MPa
Since 2006,Our equipment has been exported to many countries all over the world such as India, Pakistan, Sri Lanka, Bangladesh, Indonesia, Philippines, Malaysia, Vietnam, Singapore, Turkey, Israel, Burma, Jordan, Yemen, Iran, Iraq, Afghanistan, Syria, Kuwait, Kazakhstan, Qatar, Korea, Azerbaijan, The UAE, Bhutan, Thailand, Lebanon, Bahrain, Egypt, Libya, Ethiopia, Kenya, Somalia, Tanzania, Liberia, Ivory Coast, Ghana, Nigeria, Cameroon, Chad, Guinea, Zambia, Zimbabwe, Malawi, Congo, Gabon, Angola, Mozambique, Botswana, Namibia, South Africa, Argentina, Bahamas, Bolivia, Brazil, Canada, Columbia, Chile, Cuba, Venezuela, Ecuador, Guatemala, Guyana, Honduras, Haiti, Mexico, Peru, Uruguay, Paraguay, Surinam, Australia, Russia etc.
Our two production base of mining machinery has about 700 sets of various production equipments. Annual production capacity is 40,000 tons of mechanical products. All these make us have the ability to produce larger and special larger equipments. Our main products including: ball mill, rotary kiln, jaw crusher, cone crusher, etc. and all kinds of spare parts.
Our manufacturing base of filter equipment mainly produce full automatic or semi-automatic membrane filter press, recessed filter press, belt filter press, centrifuge, etc. All these products are widely used in mining, metallurgy, petroleum, chemical, medicine, textile, printing and dyeing, paper making, food, alcohol, inorganic salt, coal washing, and waste water processing industry.
Our products has passed ISO9001 International Quality Management System Certification and is exported to America, Canada, Chile, Bolivia, Indonesia, Malaysia, Israel, Iran, Egypt, Turkey, Romania, Sweden, Finland, etc. about more than 50 countries and area. We have won good reputation depends on our best qualified products and after-sales service. Warmly welcome new and old friends all over the world to come our company for good cooperation with each other!
All of our products:
1. Grinding mill: Rod mill, Lttice type ball mill, Overflow type ball mill, Low speed mill for coal grinding, Air-swept coal mill, Coal slurry mill, Vertical mill, Air-swept drying raw material mill, Tube mill, Swing mill.
2. Rotary kiln: Rotary kiln, Rotary kiln for construction material
3. Rotary dryer
4. Roller press machine
5. Crusher: Roller crusher, Jaw crusher, Cone crusher, High efficiency cone crusher, Impact crusher, Single-stage hammer crusher, Hammer crusher
6. Vacuum crusher
7. Apron feeder, vibration feeder, vibration screen, belt conveyor, bucket elevator, magnetic separator, flotation machine, spiral classifier and so on.
Contact infos,
Company, Zhengzhou Toper Industrial Equipment Co., Ltd
Add: No. 101, Nanyang Road, Zhengzhou city, Henan, China
Tel: 0086-371-8608-1678
Fax: 0086-371-6372-0313
Skype, chinatoper003
