copper crusher, perfect jaw crusher for gold, coppe ore
This jaw crusher can be uesd for the crushing of pebble, granite, basalt, quartz, iron ore, diabase, limestone, coal gangue, gold ore, kaolinite, dolomite, barite, gold ore, zircon, garnet, silica, manganese ore, copper, marble, feldspar, talc, sodium feldspar, ginger, rice stone, kyanite, corundum, molybdenum, mica and various kinds of ores, rocks or other materials with compressive strength not greater than 320Mpa.
Application area,
Mining, metallurgy, building material, highway, water conservancy, chemical, and many other industries, such as dry powder mortar, concrete mixing station, power plant desulfurization, quartz sand, et.
Features,
Deep crushing cavity with no dead area, improving input capacity and output capacity.
Big crushing ratio with uniform final products.
New design of discharge gate adjustment device, reliable and convenience, increasing crusher’s flexibility.
With safe and reliable lubrication system, easy to replace broken parts.
Simply structure, working smoothly, and lower operating costs.
Saving-energy, with a crusher, it can save about 15%-30%.
Big adjustment of discharge gate, it can satisfy your different requirments.
Low noise and little dust.
Working principle,
When the copper crusher works, the motor drives the belt wheel, and makes movable jaw move up and down by eccentric shaft. When the movable jaw down, the angle between the fixed jaw and movable jaw becomes smaller, and the materials can be crushed to reach the crushing target. When the movable jaw rises, the angle between the fixed jaw and movable jaw gets larger. The movable jaw plate leave the fixed jaw plate under the function of drawbar and spring, and then the crushed materials are discharged from outlet of the crushing cavity.
Technical parameters,
Model |
Feed opening size(mm) |
Max. feeding size(mm) |
Adjusting of discharge opening(mm) |
Processing capacity (t/h) |
Rotation speed of eccentric shaft (r/min) |
Motor power (kw) |
Total weight (t) |
Dimensions (L*W*H) (MM) |
PE-150*250 |
150*250 |
125 |
10-40 |
1-3 |
250 |
5.5 |
0.6 |
720*660*850 |
PE-200*300 |
200*300 |
180 |
15-50 |
2-6 |
260 |
7.5 |
1 |
910*750*990 |
PE-200*350 |
200*350 |
180 |
18-70 |
3-10 |
260 |
11 |
1.3 |
1000*870*990 |
PE-250*400 |
250*400 |
210 |
20-60 |
5-20 |
300 |
15 |
2.8 |
1300*1090*1270 |
PE-400*600 |
400*600 |
340 |
40-100 |
16-60 |
275 |
30 |
7 |
1730*1730*1630 |
PE-500*750 |
500*750 |
425 |
50-100 |
40-110 |
275 |
55 |
12 |
1980*2080*1870 |
PE-600*900II |
600*900 |
500 |
65-160 |
50-180 |
250 |
55-75 |
17 |
2190*2206*2300 |
PE-600*900 |
600*900 |
500 |
75-200 |
60-200 |
250 |
75 |
20 |
2290*2290*2400 |
PE-750*1060 |
750*1060 |
630 |
80-140 |
115-330 |
250 |
110 |
29 |
2660*2430*2800 |
PE-870*1060 |
870*1060 |
660 |
200-260 |
290-336 |
250 |
110 |
31.5 |
2810*2430*2800 |
PE-900*1060 |
900*1060 |
685 |
230-290 |
16-400 |
250 |
110 |
33 |
2870*2420*2940 |
PE-900*1200 |
900*1200 |
750 |
95-165 |
220-450 |
200 |
110 |
52 |
3380*2870*3330 |
PE-1000*1200 |
1000*1200 |
850 |
195-265 |
315-500 |
200 |
110 |
55 |
3480*2876*3330 |
PE-1200-1500 |
120*1500 |
1020 |
150-300 |
400-800 |
180 |
160 |
100.9 |
4200*3300*3500 |
PEX-150*750 |
150*750 |
120 |
18-48 |
8-25 |
320 |
15 |
3.8 |
1200*1530*1060 |
PEX-250*750 |
250*750 |
210 |
25-60 |
13-35 |
330 |
30 |
5.5 |
1380*1750*1540 |
PEX-250*1000 |
250*1000 |
210 |
25-60 |
16-52 |
330 |
37 |
7 |
1560*1950*1390 |
PEX-250*1200 |
250*1200 |
210 |
25-60 |
20-61 |
330 |
45 |
8.5 |
2140*1660*1500 |
PEX-300*1300 |
300*1300 |
250 |
20-90 |
16-105 |
300 |
75 |
11 |
2720*1950*1600 |
