40 Feet Heavy Duty Flat Deck Container Trailers for Sale

40 Feet Heavy Duty Flat Deck Container Trailers for Sale thumbnail-1
40 Feet Heavy Duty Flat Deck Container Trailers for Sale photo-1
US$ 16,000 - 20,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Semi-Trailer
Material:
Steel
Certification:
Other, ISO
Contact Supplier Request Quote Chat Now
Tantri Trailers (pvt) Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Colombo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Semi-Trailer
Material Steel
Certification Other, ISO
Size 40 Feet
Max Payload 50 ton
Place of Origin Sri Lanka
Brand Name TANTRI
Model Number TFB40

Specifications

2 x 16 ton
50 ton loading capacity
40 feet length, 8 feet width
Customer choice color
Low price

45 ft, 40 ft, or 20 ft standard or custom made semi trailers to suit the country's road regulations. Container cum platform available too, extendible & retractable trailers too could be supplied.

Specifications :-

Model                   - TFB40-2

Trailer Weight       - 6400 Kg. (unladen)

Overall Length      - 12200mm, Deck Length (40 Feet), Width - 2410mm, Height - 1500 mm

Main Frame          - High Tensile Steel 400x200x12x9 mm (main “I” beam),150x200x9x6 mm(“I” beam

                                bolsters) and 150x75x6mm (side “C” channel &cross members).

Loading Deck       - 3.5mm Steel checkered plate

Container locks    - 08 Nos. Multi Twist locks

Mudguards           - Heavy duty plastic mudguards with mud flaps.

Landing Legs        - 80,000 Kg. Static loading capacity.

Brakes                 - 2 Line pneumatic brake system with RE6 relay emergency valve.

King Pin               - 50 mm Dia forged steel King Pin

Lights                   - LED 24V light system (signal, brake, parking & number plate)

Paints                   - Shot blasted, epoxy primer coated and top coated with customer preferred colour.



Running Gear :-

Axles                     - 2 x 16 ton capacity square beam axles

Suspension            - Tandem suspension system (04 Nos. leaf spring bundles)
Wheels                  - 08 Nos. 9.25 x 22.5 , 10 Holes hub

Tires                      - 08 Nos. 295/80R x 22.5, 16PR (Tubeless Tires)



Including :-                                                                                     Options :-

Spare wheel with carrier                                                                    Headboard

Rear bumper guards                                                                         Additional spare wheel carrier

Safety crash bar both sides                                                              Tubeless tires / rims

Safety luminous fittings                                                                    Additional twist locks (If length extendable)

Hooks for tie ropes                                                                                                     Tool box,                                                                                                                                                                                                       ABS Brake
