Specifications
Screw Conveyor1.Small cross section, light weight!
2.Good transportation efficiency!
3.Flexible, easy to be installed , dism
Applications of LSY180 screw conveyor:
Spiral machine widely used in various industries, such as building materials ,chemical ,power ,metallurgy coal carbon, grain and other industries.It is applicable to level or tilted transportation of powder, granular and small block materials, such as coal ,ash ,slag cement ,grain and other materials, whose temperature is less than 200.
Parameters of LSY180 Screw Conveyor
Type |
LSY163 |
LSY180 |
LSY230 |
Spirochaeta Diameter(mm) |
163 |
180 |
230 |
Spirochaeta Speed(r/min) |
310 |
310 |
240 |
Hosing Diameter(mm) |
194x6 |
219x8 |
273x8 |
Transportation Quantity(t/h) |
35 |
45 |
65 |
Conveying Length(m) |
2-12 |
2-13 |
2-15 |
Work Position Angle |
0-60 |
0-60 |
0-60 |
Motor Type |
Y132M-4 |
Y160L-6 |
Y160L-4 |
Power(kw) |
7.5 |
11 |
15 |
Parameters of grain/cement screw conveyor
Screw Conveyor Type |
LSY163 |
LSY180 |
Spiral Diameter(mm) |
163 |
180 |
Rotation Speed(r/min) |
310 |
310 |
Housing Diameter(mm) |
194x6 |
219x8 |
Carrying Capacity(t/h) |
35 |
45 |
Conveying Length(m) |
2-12 |
2-13 |
Working Angle |
0-60 |
0-60 |
Motor Type |
Y132M-4 |
Y160L-6 |
Power(kw) |
7.5 |
11 |
Features of grain/cement screw conveyor:
1.Screw conveyor adopts excellent quality steel pipe with great property.
2.The dual blades pitch decrease the compressed material degree when conveying.
3.Adopt first grade reducer ,heavy type design ,low noise ,long rotation distance.
4.Optional universal ball joint and make installation adjust to convenience .
5.Match good quality crane and tail bearings for convenient installation.
6.Enough spare components with various specification.
7.There are plenty of stock with diameters of 165mm,219mm,273mm,323mm,407mm .And the special size can be manufactured according to customer's requirements.
8.Standard components assembly is convenient to deliver.
Application of screw conveyor :
It is widely used in various industries ,such as construction material , chemical industry , electric power,metallurgy, coal carbon,food and so on .It is applied to convey powder, graininess and small block material with level or incline.
Parameters of Screw Conveyor LSY163
Screw Conveyor Type |
LSY163 |
Spiral Diameter(mm) |
163 |
Rotation Speed(r/min) |
310 |
Housing Diameter(mm) |
194x6 |
Carrying Capacity(t/h) |
35 |
Conveying Length(m) |
2-12 |
Working Angle |
0-60 |
Motor Type |
Y132M-4 |
Power(kw) |
7.5 |
Features of screw conveyor:
1.Screw conveyor adopts excellent quality steel pipe with great property.
2.The dual blades pitch decrease the compressed material degree when conveying.
3.Adopt first grade reducer ,heavy type design ,low noise ,long rotation distance.
4.Optional universal ball joint and make installation adjust to convenience .
5.Match good quality crane and tail bearings for convenient installation.
6.Enough spare components with various specification.
7.There are plenty of stock with diameters of 165mm,219mm,273mm,323mm,407mm .And the special size
can be manufactured according to customer's requirements.
8.Standard components assembly is convenient to deliver.
