QLB60 60tph Portable Bitumen Mixing Plant With Walking System

Name: QLB60 60tph Portable Bitumen Mixing Plant With Walking System
Brand: FOCUS
SKU: 139823219
Availability: InStock

Zhengzhou Focus Machinery Co., Ltd.

US$ 10,000 - 250,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Henan, China

Brand Name:

FOCUS

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Shanghai Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Henan, China

Brand Name FOCUS

Model Number QLB60

Voltage 380v/50hz

Power(W) 157.5kw

Dimension(L*W*H) 4-10 sets of 40HQ

Weight 4-10 sets of 40HQ

Certification ISO

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

Features of portable bitumen mixing plant :

1.Batch-type dry roller and twin shaft concrete mixer, mixing evenly, better quality.

2.Accurate metering, steady quality.

3.Simple structure, easy to operate.

4.PLC control, auto or manual are both OK.

5.Walking system with tires, easy to transport and install.

6.Diesel or coal as fuel, more options for customers.

Parameter of portable bitumen mixing plant :

Model		QLB-10	QLB-15	QLB-20	QLB-30	QLB-40	QLB-60	QLB-80
Capacity		10t/h	15t/h	20t/h	30t/h	40t/h	60t/h	80t/h
Power	diesel	41.5kw	54kw	63.5 kw	104.5 kw	125 kw	157.5 kw	200 kw
Power	coal	57.5 kw	75 kw	86.5 kw	127.5 kw	169 kw	205 kw	276 kw
Aggregate batcher		--	--	2.3m3x3	5m3x3	5m3x3	5m3x3	5m3x4
Finished product bin		2t	5t	5t	9t	9t	9t	20t
Outlet Temp.		120-180℃
Fuel consumption		Diesel:5-7.5kg/t, Coal:13-15kg/t
Optional parts		Coal mill, water dust collector, bag type dust collector, control room, asphalt tank, etc.
