Dock lifter hs type 2 ton pulley chain block by chinese supplier
| Model | Capacity(T) | Standard lift(M) | Running test(T) | Max load required (N) | Fall NO.s of load chain | Dia of load chain(mm) | N.W.(kg) |
| HSZ-A1-1T | 1 | 2.5 | 1.5 | 330 | 1 | 6 | 11 |
| HSZ-A1-1.5T | 1.5 | 2.5 | 2.25 | 360 | 1 | 8 | 16.2 |
| HSZ-A1-2T | 2 | 3 | 3 | 365 | 1 | 8 | 18.5 |
| HSZ-A1-3T | 3 | 3 | 4.5 | 385 | 2 | 8 | 25.6 |
| HSZ-A1-5T | 5 | 3 | 7.5 | 435 | 2 | 10 | 42.8 |
| HSZ-A1-10T | 10 | 3 | 15 | 435 | 4 | 10 | 79.5 |
| HSZ-A1-20T | 20 | 3 | 30 | 435*2 | 8 | 10 | 193 |
| HSZ-A1-30T | 30 | 3 | 45 | 435*2 | 12 | 10 | 220 |
| HSZ-A1-50T | 50 | 3 | 75 | 435*2 | 22 | 10 | 1092 |
|
|
|
|
|
Feature:
All steel shell and the special design hand chain cover.
With the rolling bearing make the pulling more smooth and extend the service life
With double pawl and double guide wheel.
With G80 alloy steel lifting chain,standard no.ISO16877-2008
Hooks with deformation indexes to warn the overload or unreasonable operation.
With triangle forged hooks.
All products are approved with 1.5 times load testing and with the testing report.
Safety factor 4:1
This harge hoist crane from capacity 1 ton -50 ton,are compact and lightweight,easy to operate in any position and feature a ratchaet and automatic brake for secure tensioning.Specially designed for electric power,telephone line works construction,farm and general purposes,360 handle movement.
Harge hoist crane:
20cr high quality alloy steel(20cr:20Cr steel is widely used. High hardness, the steel has good hardenability, moderate strength and toughness. The matrix has high strength and toughness, which can meet the performance requirement of high hardness, high strength, high toughness and proper corrosion resistance.)
Compact inner construction:more regular accessories have been changed as more lightweight and high precision parts,you can see the assemble vedio via
Our company facebook:/jindiaohoisting/
Load chain:adopt the standard G80 heavy duty load chain,ensure the safety operate when its working.
Less required to lift max load:1.5 ton only use 330N power enough.
The difference chain cover outside see below for choose:
FAQ:
Q1:Are you a factory
Yes,we are the manufactory since year 1930 when my boss's grandpa was young and established our export license since year 2012 export those chain blocks and lever hoists to many countries.
Q2:What is your payment terms?
1.TT:30% advance,balance against copy docs(packing list and commercial invoice and B/L)
2.L/C at sight acceptable.
3.Western Union available.
Q3:How your service after order confirmed?
1.-We will have a report file to our customer about the production process everyweek.
2.-Vedio of testing available before packing.
3.-QC report file will be supplied with signed and stamped by our company to our customer
Q4:Certification available?
Yes,all the commodities with CE certifications.
Q6:What is the running test report?
Every chain blocks and lever hoist need to be tested before packing avoid any problems.
1.5 times heavy duty of steels be sure the shaking when its operating.
Q7:What is the max broken capacity of this commodities?
Actully we wil pass our products for 4 times broken testing,finnally the hooks will be straighted but not be breakdown,the quality of safe is the most important requirements.
The broken test vedio can be send you for refer if you want.
Q8:How can I send you inquiry?
You can have the inquiry write here or send directly via my whatsapp:+86 138 6718 7601 as for the vedio or real images of its commodities.
reply will given to you within 12 hours.
