professional ring die alfalfa pellet mill
Description of alfalfa pellet mill
alfalfa pellet mill is also called biomass fuel solid shaping machine , it is a type of equipment which can compress various scattered and shapeless agricultural and forestry biomass into molded fuels in the shape of rod or lump or pellet, through collection and drying and grinding under a certain temperature and pressure.
A kind most widespread machine in China and abroad.
alfalfa pellet mill Use Raw Material:
The pellet mill is suitable to make no oily and which are dried by driers, such as rice husk, sawdust, cotton stalks, cottonseed skins, rank grass, and other crops straw and plant waste. The equipment is also widely used in power plant, wood processing plant and biomass fuels plant.
Advantage points of alfalfa pellet mill
1.Feeding vertically and directly to pelletizing room.
2. Die static, rollers rotating, materials centrifugal, evenly distributed around.
3 Double-layer dies, up and down dual use, high capacity and energy saving.
Working principle of alfalfa pellet mill
It's easy to make the biomass particle,small size material feeding into the particle machine, two rollers woll press thematerial into the 6or8mm stainless steel ring die to form a solid particle. However, different material needs different ring die, mainly depending on the material compress ratio, we design the taper and thickness to creat press for the lignin to reach sufficient temperature and bind the material together.
Technical Parameters of alfalfa pellet mill
| Modle | Power(KW) | Capacity(T/H) | Weight(T) | Size(mm) |
| TCZL-560 | 90 | 1-1.5 | 6 | 1350*850*1500 |
| TCZL-650 | 160 | 1.5-2 | 9 | 1850*1050*1800 |
| TCZL-850 | 220 | 2.5-3 | 1414 | 2150*1180*1950 |
| TCZL-960 | 315 | 3-4.5 | 18 | 2430*1380*2100 |
| TCZL-1050 | 315 | 4.5-6 | 24 | 2800*1500*2500 |
1. We treat customers as gods, and provide considerate services from shipment to maintenance, including professional free training, guidance, installation,and debugging.
2. After sale, we provide one year's warranty. we will help to solve any mechanical problems in time. Also engineers are available to service overseas
Jinan Taichang Transmission Machinery Co.,Ltd located in Shandong province,China. Our factory is a professional manufacturer of biomass pellet machine for agriculture, forest, pasturage,fishery for many years.
Our company has passed ISO9001-2008 quality certification and CE certification.
In order to offer you the reasonable machines,we need more details as followings:
1.The raw materials and the size you used.
2. Moisture content of the raw materials or give me the picture of raw materials.
3.The size of pellet you needed.
4.The voltage frequency in your country.
5.The output you needed in one hour.
If you are interested in the above products, please feel free to contact us, thank you for your attention!
