Specifications
Water Treatment System Chlorine Dioxide GeneratorsClO2 can disinfect all kinds of microorganism
Water Treatment System Chlorine Dioxide Generators
RFS series chlorine dioxide generator
The advantage of chemical Chlorine dioxide disinfection of sewage treatment process:
1, ClO2 can disinfect all kinds of microorganism, including: Multiplication of bacteria, Cells spores, fungus , mycobacterium, and viruses etc. and also micro organic contaminants in water, such as: anthraquinone benzopyrene, chloroform, carbon tetrachloride, phenol, chlorophenol, cyanide, hydrogen sulfide and organic sulfides etc.
2, ClO2 can oxidation the Fe2+, Mn2+, Ni2+ etc. less influence from PH, disinfect alga, less color, turbidity and odor.
3, The effect is five times than NaClO3.
4, ClO2 is the most disinfection method in medical sewage treatment.
4, The effect of ClO2 disinfection is better than ozone and chlorine, the time of ClO2 disinfection is 1/2-1/4 less than chlorine, the reaction pool is half smaller, save the cost.
Model |
Producing capacity g/h |
Power Kw |
Pipe Dia. DN |
Power water pressure Mpa |
Weight kg |
Area m2 height m |
RFS-50 |
50 |
0.5 |
25 |
0.15 |
55 |
0.3X1.5 |
RFS-100 |
100 |
0.5 |
25 |
0.15 |
62 |
0.3X1.5 |
RFS-300 |
300 |
0.8 |
25 |
0.15 |
78 |
0.3X1.5 |
RFS-500 |
500 |
1.2 |
25 |
0.15 |
105 |
0.4X1.5 |
RFS-800 |
800 |
1.5 |
25 |
0.15 |
135 |
0.4X1.5 |
RFS-1000 |
1000 |
2.0 |
32 |
0.2 |
155 |
0.55X1.5 |
RFS-2000 |
2000 |
2.5 |
32 |
0.2 |
178 |
0.55X1.5 |
RFS-5000 |
5000 |
3.5 |
40 |
0.2 |
210 |
0.65X1.5 |
RFS-8000 |
8000 |
3.5 |
40 |
0.2 |
230 |
0.8X1.6 |
RFS-10000 |
10000 |
4.5 |
50 |
0.25 |
245 |
0.8X1.6 |
RFS-20000 |
20000 |
4.5 |
50 |
0.25 |
280 |
0.8X1.6 |
|
|
What we can provide
Paper making process:
--Pulping System
--Screening System
--Conveying and Bale Breaking System
--Pulp Refining Equipment
--Impurity Cleaning Equipment
--Stock Agitator Conveying Equipment
--Pulp Thickening Equipment
Paper Making Production Line (paper MPL):
--All kinds of raw paper pulp MPL
--Fluting paper pulp MPL
--Automatic corrugated box/paper MPL
--Coated White Board paper MPL
--Honeycomb paper MPL
--Testliner paper MPL
--Paper plate MPL
--Tissue paper MPL
--Toilet paper MPL
--Kraft paper MPL
--Boxboard paper MPL
--Paper coating MPL
--Napkin paper MPL
--OCC line
Please supply the information below:
--what is the producing capacity demanded?
--what is the original paper?
--what is the outlet paper demanded?
Then we design the paper mill project plan.
Zhucheng Yonglida Machinery Limited Company is located in Zhucheng city, Shandong province, China and founded in 1993 covering an area of 30,000 square meters. It is the high technology factory combined with design, development, production and technical service and leads the papermaking equipment and environmental protection equipment industry in China.
Main products: Toilet paper making machine, cardboard paper making machine, corrugated paper making machine, craft papermaking machine, environmental protection equipment, daily and city waste water and daily garbage treatment equipment, industry waste water and garbage treatment equipment, paper making, printing, starch, medical and mine industry waste water treatment equipment, etc.
Yonglida has operated several papermaking system and environment protection project domestic and foreign, including Russia, Egypt middle east, etc. We can also make the proper project plan as customer’s requirement.
Welcome to visit our factory, hope we could have a long cooperation relationship and business win win.
|
|
